HT582 585nm Orange Infrared Laser Test Card

HT582 585nm Orange Infrared Laser Test Card thumbnail-1
HT582 585nm Orange Infrared Laser Test Card photo-1
US$ 50 - 1,000 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
KPT
Model Number:
KPT-6505CF
Contact Supplier Request Quote Chat Now
Shanghai Keyan Phosphor Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name KPT
Model Number KPT-6505CF

Specifications

It functions with 1mW of IR Laser sources, efficient excitation wavelength arrange mainly from 800nm to 10600 nm.

INFRARED (IR) LASER TEST CARD

By converting kinds of invisible near infrared wavelength beam into visible light, IR Laser Test Card is able to detect, track, proofread and identify infrared beam efficiently from various kinds of semiconductor lasers, YAG large laser, IR LED etc. and also been applied in fields of optical fiber communication and medical inspection etc.

It's a kind of power, ceramic or glass agglomeration made up of up conversion phosphor with average particle size arranging from 0.4μm to 50μm.  It has characteristics as sensitive response, rich glowing color, high concealing ability and reliability, easy test and long lifetime etc.

It functions with 1mW of IR Laser sources, efficient excitation wavelength arrange mainly from 800nm to 10600 nm.

Different wavelength IR laser can be identified by the same IR Test Card; Its brightness will go up along with IR devices excitation power increasing;

Visible Emitting spectrum: Orange red 580-620nm, Blue 430-450nm, Green 530-560nm;

Paper, plastic, glass, mental, and ceramic material test cards are available; Specifications, shape, color etc. can be made according to customers’ requirements.

HT582 585nm Orange infrared laser test card


TECH DATA

Model

Color

Excitation  wavelength at peak (μm)

Excitation Frequency(nm)

Absorbtion

UV  3650

Excitation Wavelength Spectrum
(μm)

HT612

Red

1.0-1.3

630

Red

0.8-1.6

HT582

Orange

0.80-1.3

585

Orange

0.7-1.4

HT520

green

0.80-1.3

520

green

0.7-1.8

HT510

green

0.80-1.3

510

Weakness green

0.7-1.4

HT513

Green

0.9-1.06

520

Green

0.80-1.3

HT412

Green-blue

0.90-1.06

490

Green-blue

0.80-1.3

HT320

blue

0.90-1.06

470

Blue

0.80-1.3

HT111

Green

0.98

520

---

0.80-1.06

HT112

Blue

0.98

470

----

0.94-1.06

HT113

Red

0.98

610

-----

0.94-1.06



HT582 585nm Orange infrared laser test card
