1064nm Infrared Test Card,ir Test Card
- Shanghai Port
- T/T Money Gram Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | KPT | |
| Model Number | HT510 |
box
Product Description
Specifications
It functions with 1mW of IR Laser sources, efficient excitation wavelength arrange mainly from 800nm to 10600 nmINFRARED (IR) LASER TEST CARD
By converting kinds of invisible near infrared wavelength beam into visible light, IR Laser Test Card is able to detect, track, proofread and identify infrared beam efficiently from various kinds of semiconductor lasers, YAG large laser, IR LED etc. and also been applied in fields of optical fiber communication and medical inspection etc.
It's a kind of power, ceramic or glass agglomeration made up of up conversion phosphor with average particle size arranging from 0.4μm to 50μm. It has characteristics as sensitive response, rich glowing color, high concealing ability and reliability, easy test and long lifetime etc.
It functions with 1mW of IR Laser sources, efficient excitation wavelength arrange mainly from 800nm to 10600 nm.
Different wavelength IR laser can be identified by the same IR Test Card; Its brightness will go up along with IR devices excitation power increasing;
Visible Emitting spectrum: Orange red 580-620nm, Blue 430-450nm, Green 530-560nm;
Paper, plastic, glass, mental, and ceramic material test cards are available; Specifications, shape, color etc. can be made according to customers’ requirements.
Model | Color | Excitation wavelength at peak (μm) | Excitation Frequency(nm) | Absorbtion UV 3650 | Excitation Wavelength Spectrum |
HT612 | Red | 1.0-1.3 | 630 | Red | 0.8-1.6 |
HT582 | Orange | 0.80-1.3 | 585 | Orange | 0.7-1.4 |
HT520 | green | 0.80-1.3 | 520 | green | 0.7-1.8 |
HT510 | green | 0.80-1.3 | 510 | Weakness green | 0.7-1.4 |
HT513 | Green | 0.9-1.06 | 520 | Green | 0.80-1.3 |
HT412 | Green-blue | 0.90-1.06 | 490 | Green-blue | 0.80-1.3 |
HT320 | blue | 0.90-1.06 | 470 | Blue | 0.80-1.3 |
HT111 | Green | 0.98 | 520 | --- | 0.80-1.06 |
HT112 | Blue | 0.98 | 470 | ---- | 0.94-1.06 |
HT113 | Red | 0.98 | 610 | ----- | 0.94-1.06 |
HT900 | Red | 0.98 | 610 | ---- | 1.5 or 0.98 |
HT800 | Green | 0.98 | 510 | Green | 0.8-10.6 |
HT815 | Black | 3-5 | Blue-green | ----- | 1-10 |
HT700 | Red | 0.98 | 630 | Red | 0.8-2.0 |
Factory information:
Customer visiting:
Company Profile
Shanghai Keyan Phosphor Technology Co., Ltd. (KPT CO.) is a High tech enterprise engaged in making and supplying various types of phosphor light material and instruments since 2000 year in Shanghai China. The products include EL electroluminescent wires, phosphors (also called EL wires, flexible neon wires, cool wires, cool neon, and rope lighting glow toys), Christmas lighting decoration, garden illumination, intellect twinkling toys, clothing, darkness safety signs, car decoration, and flexible neon advertisement. Our company researched EL materials with glass and enamel to make flat lighting displays and phosphor instrument since 1965 and plastic EL panels in 1980. In 1990, we started our work on flexible neon wires (EL wires); and in 2000, we were supported by China government for mass production of EL wires and various kinds of phosphor materials. We are equipped with advanced production and test machines for EL wire and phosphor materials and have strong new product development ability. Now we owned over 20 patents for all of our products, among which KPT and EL wire are exported to over 30 overseas countries. Meanwhile, we can supply tech consulting service for domestic and worldwide customers. If you are interested in any of our products, please feel free to contact us. ADD: Building 8 ,No.8 ,Dongzhou Rd ,Dongjing, Songjing, Shanghai, P.R. 201619,China
