Specifications
Shortcut hand made flexible neon lighttwinkling,steady light
high bright and long lifetime
energy save and low power
newest
USB connector chasing wire
More core dynamic flexible neon line can be also called as more core electricity light/wire, glowing assembly line, chasing light, polishing wire, trotting horse lamp line, three regimes flash line etc.
Technical principle:
general electric light is made by single metal copper core line, the performance can be only normally on and flicker across. Many core dynamic flexible neon line is consisted of several metal copper core line winding and can control metal copper core respectively,and through the way of multipath drives control flashing, realizing all kinds of different types of flashing combination.
More core dynamic flexible neon line usually with wire core of 0.1 mm copper wire,made with 9 root or 6 root spiral together. When using, it can be three root or two root a group of form all the way electrode, each electrode corresponding multipath drive's circuit.
The main technical indexes:
re wire quantity: 6 core, 9 core;
2.Spiral distance: 4 mm, 8 mm, 12 mm or so;
3.El wire outside diameter: 1.2 MM and 2.0 MM, other customizable;
4.Shape: round and other customizable;
5.Common color: transparent, blue, red, and other customizable;
Regards the driver/inverter,we only have samples now, if other customers needs,they need to design or manufacture themselves.
Use and effect:
1.it can be made into flashing electric wire, such as power supply socket connection, -le phone charger line, USB interface wire, audio headset wire;
3.the speed of the flashing of the chasing wire is depend on magnitude of current ,
4.the music frequency control flashing;
5.data flows through a wire will make the direction of occurs when walking around, etc.
