Copeland ZW Series commercial hot water heating system
Aseair Commercial Air Source Heat Pump Water Heater delivers hot water for large hot water demand in hotel, resort, club, school, villa, factory, sauna and SPA etc, as a new trend of cost-effective water heating solution in the world.
COST-EFFECTIVE WATER HEATING SOLUTION
The Aseair heat pump has been made to highest quality standard with international brand of components which enables the best efficiency, durability and reliability with characteristics of competitive price and high COP that to provide a cost-effective water heating solution.
LARGE HOT WATER SUPPLY
It has more powerful heating capacity with high efficiency that could supply 210 to 1,900 liters 40 to 55°C hot water per hour for the large and quick hot water heating demand.
EASY INSTLLATION & OPERATION
Smaller space for installation when compared with solar water heater . It just requires connection of water pipes and electricity power supply with no special care will be taken. It will operate on its own according to the set parameters on controller which is installed indoor at the place that easy to access and observe.The product can work individually or compactible with solar water heater, boiler, electric geyser as supplementary in order to achieve increasing power or retrofitting.
| TECHNICAL SPECIFICATION | ||||||||
| Model Number | AWH-010UVC | AWH-018UYC | AWH-023UYC | AWH-036UYC | AWH-043UYC | AWH-070UYC | AWH-090UYC | |
| Function | Heating, Auto Defrost | |||||||
| Heating Capacity * | kW | 10 | 18 | 23 | 36 | 43 | 70 | 90 |
| Input Power | kW | 2.6 | 4 | 5.75 | 8.95 | 9.35 | 17.1 | 21.9 |
| COP | 3.9 | 4.5 | 4 | 4.02 | 4.6 | 4.1 | 4.1 | |
| Power Supply | V-Hz | 230V/1N~ 50Hz | 380V/3N~ 50Hz | 380V/3N~ 50Hz | 380V/3N~ 50Hz | 380V/3N~ 50Hz | 380V/3N~ 50Hz | 380V/3N~ 50Hz |
| Delivered Water Temperature | °C | Max. 60°C | ||||||
| Delivered Hot Water Volume | Ltr/h | 210 | 380 | 490 | 770 | 925 | 1500 | 1900 |
| Sound Pressure Level ** | d(B)A | 56 | 53 | 54 | 59 | 65 | 69 | 72 |
| Packing Dimension | mm | 800x740x1000 | 800x740x1200 | 800x740x1400 | 1550x740x1200 | 1550x740x1400 | 2260x1360x2270 | 2260x1360x2270 |
| Net/Operating Weight | kg | 110/125 | 130/150 | 150/170 | 290/330 | 350/390 | 700/750 | 800/850 |
| Operating Ambient Temperature | °C | -10 to +43 | ||||||
| CONFIGURATION | ||||||||
| Compressor | Hermetic, Flexible Scroll | EVI Scroll | Hermetic, Flexible Scroll | |||||
| Refrigerant Gas Type | R407c | |||||||
| Controller | Aseair Hot Water LED Controller | |||||||
| Water Heat Exchanger | Copper Tube-in-Shell/Tube-in-Tube | |||||||
| Water Pump | Optional | Optional | N/A | |||||
| Air Heat Exchanger | Aluminum Hydrophilic Fin-Tube | |||||||
| Expansion Valve | Thermal Expansion Valve | |||||||
| Ventilator Qunatity & Type | x1 Vertical Axial | x1 Vertical Axial | x1 Vertical Axial | x2 Vertical Axia | x2 Vertical Axia | x2 Vertical Axia | x2 Vertical Axia | |
| * At air 20°C, water heated from 15°C to 55°C; | ||||||||
| ** Sound pressure level was measured at a distance of 1 meter | ||||||||
Main components
Our Suppliers
Project Photos
Quality control:
Every heat pump with four times detection of performance and protection in the FQC Central.
Every orders with the comprehensive detection from random inspection in the LAB.
1.Material Quality Control
2.Process Quality Control
3.Mass Products Quality Control
4.Outcoming Quality Control
5.Ready For Delivery
LAB
FQC Central
Why Aseair?
1.Over 18 years experience in heat pump system industry.
2.Customers favorite top 10 heat pump brand in China
3.The strategic partner of US Emerson and Denmark Grundfos.
4.Frequent exchange experience with European heat pump suppliers and distributors, constantly improve ourselves.
5.We choose the international famous heat pump components suppliers, to keep our heat pump high quality, high efficient and running stable all the years, all weather.
6.We are the reputable manufacturer, our products with reasonable factory price.
7.Provide not only products but also best solutions.
About us:
1.In 1996, we were called as Aoke and supplied the central air-conditioning. In 1998, we started to specialized on the field of heat pump. Later, we got more and more stronger, in 2008, Aseair was established and keep growing fast so far.
2.We are famous for our heating system, which in the leading position in China.
3.Our 12 engineers ready to make the solutions for you.
4.Under Aseair,we have three subsidiaries, Shandong Production Base, Shandong Heat Energy Engineering, Foshan Ghangcheng Air-conditioner Engineering.
5.Certification: SGS, CCC, ISO9001, ISO14001,OHSAS18001
Customization:
Refrigerant : R407C/R404A/R410A/R134A. Optional
Metal sheet: stainless steel#304, #316, galvanized sheet
Quality
We Aseair the first mission is to bring the stable warm to people all the years. Therefore we adopt the international famous components. With the high performance, COP up to 3 average in all around the year. Design for operating stable more than 12 years. Choose Aseair, the meaning of choosing high experience.
China heat pump engineering case1
.
China heat pump engineering case2
1.Plywood Pallets with crate to protect heat pump during transportation
2.Bottom fixed with screws to make sure delivery stablility.
3.T/T Payment.
1. Answer enquiry from customers In the shortest time.
2. Provide perfect technical service for customers by professional engineers.
3. Produce heat pump according to customer's special demands.
4. Provide perfect after-sale service for customers, 18 months warranty for all heat pumps .
5. Provide OEM service for customers.
Guangdong Aseair Heat Pump Co., Ltd. focuses exclusively on manufacturing heat pump with history of 13 years.
The company has production facilities over 25,000sqm where more than 50,000 units of heat pump were produced each year. By now Aseair had been the leading company in the industry of heat pump in China.
Since 2000, the Aseair heat pumps had been exported to countries in Oceania, Asia, Europe, South America, South Africa. The main products are air source heat pump for house heating and DHW
Our company has strict management of production and quality control. From every beginning, we had obtained the certificates of ISO9001:2008 Quality Management System, ISO14001:2004, OHSAS18001:2007, Production Licensing of Industrial Products of China and Audited Supplier Certifications issued by SGS and TÜV, China CCC certificates, CE certificates, CB certificates, as a qualified partner of each of our customers worldwide.
