Specifications
do fast cutting first then with 3.5kw spindle,do normal engraving.DSP control system
Professional cylinder working lathe
CNC mini lathe engraving/cutting machine and distributors wanted model CC-K3015
Our company has powerful strength in Machining. In order to make sure every detail's high quality level, most of the machine's metal parts are made by our own Machining Center imported from American.
Detailed Features:
1. With which can do any cylinder's engraving and cutting, milling, the processed cylinder diameter can be up to 300mm, length can be 1500mm.
2. With Scanner or designed photo, it can do any 3D Engraving
3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
4.Has the rotary which is used for engraving cylinder workpiece.
5.Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
6.Has the function of re-carving after break point and power failure.
7. Adopting advanced DSP system with USB connection, operated with the handle
Technical Specifications
Description |
Parameter |
Optional parameter |
4th rotary axis max diameter |
300mm |
250mm, 200mm |
Machine dimension |
1800mm*1450*1450mm |
|
Resolution |
0.01mm |
|
Lathe structure |
Seamless welded steel structure |
|
X,Y structure |
Rack and pinion transmission, Hiwin square guide rail |
|
Z structure |
Imported ball screw |
|
Max. idling speed |
35m/min |
|
Spindle motor power |
3.0 KW |
4.5kw |
Spindle rotate speed |
0-24000r/min |
|
Working voltage |
AC380V/50Hz |
220v |
Working mode |
Stepper |
|
Cooling mode |
Water-cooling |
Air-cooling |
Dust-collect function |
Yes |
|
Work-holding |
By clamp |
More machine:
3D Multi Heads CNC Router Machine with 8 Rotaries:
this model has Two Functions,
one isPlane Table for Plane material Cutting and Engraving.
The second funtion is 8 Rotaries for do Cylinder / Round Material Engraving and Milling.
If you With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving .
Applicable industries:
Wood processing: processing of various furniture such as door, window, cabinet, craft wood door, screen and so on.
Advertisement: engraving and cutting various labels and number plate.
Art craft: engraving characters of any languages and graphics on gifts and souvenirs.
Applicable materials:
Wood, aluminum board, plastic, density board, wave board, PVC, acrylic,crystal, light marble and other nonmetal materials and light metal materials.
Standard exported Wooden case
Shandong Chencan Machinery Co.,Ltd. is a High-tech enterprise product and production.
Located in Qihe Economic Development Zone,Shangdong Province,with floor space of 20000square meters
and 13000square meters of modern workshops,160 employees and total assets nearly 60 million yuan.
All products have obtained the Euro CE and ISO9001Quality Management System Certificate and self-managed import and export right.
As we are manufacture ,we are looking for distributors.
