Specifications
4axis chair legs carving cnc machineheavy duty lath body
steeper motor and driver
Weihong 74A control system
CE&ISO certifi
4axis table legs carving cnc machine
CC-M5024G
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
Ideal for:
Staircase column, curved circular retire vases, tables, chairs, Roman column Continental furniture, wooden hangers and the complex shape of the washbasin, cylindrical, conical, curved, spherical rotary the body wood products or semi-finished products in wood ,foam is ok.
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
Main features
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
It can add a plate to do the plat work also .
1.Heavy Lathe bed welded with thick channel steels and square tubes;processed by high temperature tempering treatment and vibrating stress relief(VSR) to reduce residual stress;ensure excellent stability,not easy to be deformed.
2.X Y axis adopt rack and pinion transmission , widening Taiwan Hiwin linear guide rail,Z axis adopts imported Taiwan ball screw ;self-lubricating sliding block. when engraving, equal force in all directions, to ensure the accuracy and strength.
Imported ball screw hiwin guide rail and block
Helical rack and pinion
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
Original NC studio operating system,connected with computer ,makes operation easy and visualized.Also there is hand wheel can use ,operate easily.
Weihong Handle wheel
wood cylinder cnc engraver machine/ cylinder engraving machine for wood/ cnc cylinder wood engraving machine
Be compatible with several CAD/CAM designing software, e.g.Type 3,Artcam ,castmate,ucancam
Has the function of re-carving after break point and power failure.
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
|
Model |
CC-M5024G |
WORKING SIZE |
Diameter500mm*2400mm length |
Table face |
Plat:Aluminium t-slot and PVC Fix the materials by clamps |
Transmission |
XY rack and pinion ,Taiwan Hiwin guide rail H20, and blocks,Z imported ball screw |
Spindle |
4.5kw water cooling |
Collect |
ER25 |
Spindle rotating speed |
0-24000r/min |
accurancy |
0.2mm |
Max. Idling speed |
35m/min |
Working mode |
Stepper motor and Yako driver |
Inverter |
Fuling 5.5kw |
Control system |
Weihong 74A |
Diameter of cutter |
φ3.175-φ12.7mm |
Voltage |
AC380V/50Hz,3ph |
Software |
Type 3, Artcam, Wentai |
Command |
G code,HPGL,U00,MMG,PLT |
Gross Weight |
1000kgs |
Package |
Plywood case |
4axis chair legs carving cnc machine/ 4axis wood legs carving cnc machine/ 4axis chair legs turning machine
4axis rotary 3d cnc carving machine/ 4axis 3d carving cnc machine/ 4axis rotary wood carving machine
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
samples
hot rotary wood carving cnc machine/ cnc machine for rotary wood carving/ rotary engraving cnc machine
wood cylinder cnc engraver machine/ cylinder engraving machine for wood/ cnc cylinder wood engraving machine
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
4axis rotary 3d cnc carving machine/ 4axis 3d carving cnc machine/ 4axis rotary wood carving machine
4axis table legs carving cnc machine/ 4axis wood legs carving machine/ 4axis table legs turning machine
