Heavy model Professional CNC Router for Wood & Fome Mold : CC-BS1325BH
Applicable materials:
Wood, EPS and non-metallic materials.
1. Mold industries:
sculpture various large non-metallic mold can be particularly suitable for any kind of
Foam (EPS)mould, wooden ship model,wooden model aviation and other wooden mould.
2.Musical instrument industry: Can carve three dimension musical instrument, contour cutting.
Processing effect:
It can manufacture the following effects: engraving, cutting, milling ,drilling, relief, shadow,
enchasement and so on.
Features:
1. Perfect Control Box: trinity with Install the software system, Control system's
installation, Control and operate machine . And it can put the full set computer,
key board . Reasonable, Humanizing dustproof design.
2. Heavy mode Lath body, welded by thick hard steel, to make sure the
machine's high stability, precision and efficiency working
3. Original Version NC Studio Control system, that the machine can be controlled ,
designed and operated by the computer directly. With high precision, specially
for the high requirements for round designs' precision processing.
4. Bistratal Side panel, to make sure the gantry's high supporting power
5. Japan Yaskawa Servo Motor and Drives, let the machine keep high stability,
precision and efficiency working
6. Professional used for any kind of mold's making with Solid Wood, Foam(EPS) materials.
Especially suitable for foam automotive molds, wooden ship
molds, wood mold for metal casting,
advertising foam mold , and other molds' precise making
7. Effective working Area: 1300mm*2500mm*500mm
Basic Advantages:
A. High soft, famous brand electric cables, with high Abrasion, fold, high temperature ,
acid and alkali resistant .
B. Original Imported Taiwan Hiwin Guide Rail , Taiwan / Germany Imported ball screw.
C. We will provide you several kinds software for free, with English and multilingual versions.
Also you can get the perfect picture storage with thousands 2D and 3D designs ,
and some kinds of spare parts, work piece fixtures .
D. Perfect after sale service, timely reply to your any question, professional instructions
for the machine, software and parts' using.
E. Any workstage is strictly processed according to Euro CE Quality Standard and
ISO Quality Standard .
Any set CNC Router will be done at least 72 hours careful testing and checking,
from small part to the whole machine .
After any part's quality inspection, finishing Basic maintenance measures, then
the machine can be packaged by the specialized workers for transport.
F. Our company has powerful strength in metal Machining. In order to make sure every detail's high quality level,
most of the machine's metal parts are made by our own Machining Center imported from American .
PARAMETERS
Model |
CC-BS1325BH |
Lathe body |
Thick Hard Steel structure (sand blast & seasoning) |
X Y Z effective working area |
1300*2500*500mm |
Precision Machining |
0.1mm/1000mm |
Max Traverse Speed |
30000mm/min |
Max processing speed |
20000mm/min |
Table size |
1500*3800mm |
Resolution |
0.01—0.03 mm |
Spindle power rate |
6KE HSD Italy Air-cooling spindle |
X,Y structure |
Rack and pinion transmission, Big size Taiwan-made Linear Bigger orbit |
Z structure |
Germany-made ball screw |
Guide Rail |
Hiwin—30mm |
Spindle rotating speed |
0-18000r/min |
Standard Power |
AC380V-/220V-Three Phase (Optional) |
Max. idling speed |
30000mm/min |
Cooling mode |
Water-cooling |
Command |
G code,HPGL,U00,mmg,plt |
Dust-collect function |
Yes |
Operating system |
DSP system |
Diameter of cutter |
φ3.175-φ20 |
Working mode |
SERVO |
Side Picture of CC-BS1325BH Model Foam CNC Machine
Wooden sample made by CC-BS1325BH Model Foam CNC Machine
Perfect Gantry picture of CC-BS2030BG Model Foam CNC Machine
Samples:
