Features:
1. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
2. The machine adopts gantry movement, it can process any kinds of materials freely.
3. Three axes adopt Hiwin high precision square orbit; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost; Z axis adopts Germany-made ball screw,with high precision and long life time.
4. Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
5. Has the function of re-carving after break point and power failure.
6. Has the function of forecasting process time.
7. Adopting advanced DSP system with USB interface, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
8. Perfect oil-inject system makes maintenance much easier. All the linear guides are centrally lubricated from a central system
9. Has duct-collect function. It will clean up the carving residuum and make the operations tidier and more convenient.
10.Advanced design of the machine make sure strong cutting and guarantee the engraving precision.
Application:
Our 1325 cnc is widely used for cutting, milling, boring and engraving on various wood materails.
Sample:
Door Engraving
3D relief engraving
Milling
Cutting
Packing: Strong Plywood box for Sea shipment
Technical Specifications
Description |
Parameter |
X,Y working area |
1300*2500mm |
Z working area |
200mm |
Table size |
1440*3040mm |
Resolution |
0.01mm |
Lathe structure |
Seamless welded steel structure |
X,Y structure |
Rack and pinion transmission, Hiwin square guide rail |
Z structure |
Imported ball screw made in Germany, Hiwin square guide rail |
Max. idling speed |
35m/min |
Spindle motor power |
3.0 KW |
Spindle rotate speed |
0-24000r/min |
Working voltage |
AC380V/50Hz |
Working mode |
Stepper |
Command |
G code (HPGL,U00,mmg,plt) |
Operating system |
DSP |
Diameter of cutter |
φ3.175-φ12.7mm |
Cooling mode |
Water-cooling |
Dust-collect function |
Yes |
Work-holding |
By suction or clamp |
