3D Multi Spindle Wood and Cylinder Engraving Machine With 8 Rotaries Device

Name: 3D Multi Spindle Wood and Cylinder Engraving Machine With 8 Rotaries Device
Brand: CHENCAN
SKU: 130420335

US$ 19,999 - 27,999 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Place of Origin:

Shandong, China

Shandong Chencan Machinery Incorporated Company

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Place of Origin Shandong, China

Brand Name CHENCAN

Model Number CC-MS3020K-8

Voltage AC380V-/220V-Three Phase

Dimension(L*W*H) 2140*3400mm*2300mm

Weight 2100KG

Certification CE,ISO

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

CNC eight spindle wood and cylinder Engraving machine router with 8 rotaries do circular cylinder work

Model: CC-MS3020K-8

8 spindle with 8 rotaries router Working video link: http://youtu.be/cEwmebn_BzE

12 spindle with 12 rotaries router Working video link : http://youtu.be/pf_mKsmPe_Q

Product Description

Detailed Features:

1. CC-MS3020K-8 model machine is the 3D , 4 axises CNC Router Machine, with 8 Rotaries and 8 spindles, which can work at the same time or independently, and every one's max effective working area is 225 mm(diameter) by 3000mm(length).
2. Two Functions, one is Plane Table for Plane material Cutting and Engraving. The second function is 8 Rotaries for do Cylinder / Round Material Engraving and Milling. If you With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving .
3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
4.Adopting 5sets high-torque YASAKWA servo motor and 3D & 4Axis NC studio control system
5. X and Y axes adopt rack and pinion transmission, faster working, higher efficiency and low cost. Z axis adopts Germany-made ball-screw and Taiwan Hiwin H30square orbit, with high precision and longevity.
6. Advanced file pretreatment function can correct the error in the files and is compatible with the process codes of multiple national and international software.(such as Mastercam, Type3,Artcam) .
7.High soft, famous brand electric cables, with high Abrasion, fold, high temperature , acid and alkali resistant .
8. We will provide you several kinds software for free, with English and Multilingual versions(CAD/CAM designing software e.g. Type 3/Artcam/etc.). Also you can get the perfect picture storage with thousands 2D and 3D designs, and some kinds of spare parts, work piece fixtures.
