Specifications
1. working material: marble, granite, stone, metal2. working size: make machine as your need
3. 4.5KW water-cooling spindle
Headstone and Grave CNC Engraving router
Features:
1. Lathe bed is welded with thick square tube and is processed by high temperature treatment, good rigidity and heavy loading.
2. Three axes adopt Hiwin high precision square orbit; x and y axes adopt rack and pinion transmission, fast working, high efficiency and low cost; z axis adopts imported ball screw, with high precision and long life time.
3. Main spindle: 3.0kw less noise, strong power and high precision
4. The machine has water tank and automatic water cooling system
5. Adopting advanced DSP system with USB connection, operated with the handle, convenient operation.
6. Waterproof and dustproof design for the machine products the transmission parts from broken.
7. Well compatibility: CAD/ CAM designing software e.g. Type3/ Artcam/ Castmate/ Wentai etc.
Sample:
Technical Parameter:
Description |
Parameter |
X,Y,Z working area |
1300*2500mm*200mm |
Max Engraving Depth |
150mm |
Table size |
1440*2640mm |
Resolution |
0.05mm |
Lathe structure |
Seamless welded steel structure |
X,Y structure |
Pack and pinion transmission, Linear orbit |
Z structure |
Imported ball screw |
Max. idling speed |
30m/min |
Spindle motor power |
3.0KW water cooling |
Spindle rotate speed |
0-24000r/min |
Working voltage |
AC380V/50Hz |
Working mode |
Stepper |
Command |
G code, HPGL, U00, mmg, plt |
Operating system |
DSP |
Interface |
USB |
Diameter of cutter |
φ3.175 , φ6 φ, 12.7mm |
Dust-collect function |
Yes |
Working-holding |
By clamp |
Net weight |
2000KG |
Where could we use CNC woodworking routers?
Our CNC woodworking routers are primarily used in woodworking industry. For example, they can be used in furniture decoration industries for furniture decoration,
wooden door and window frame processing,and wooden craft industry,and more. They can also be used for manufacturing sewing machine tables and cabinet panels,and more.Further more,a woodworking CNC engraving machine can also be used in musical instrument manufacturing industry to finish 3D woood carving,whether it is relief cutting or profile cutting.Utilized in mould making industry to process wooden mould is also possible.
Although it is named as a CNC woodworking router, it is not exclusively applicable for wooden materials. Our woodworking CNC engraver is also suitable for engraving on acrylic materials,
double-color boards,PVC/EVS and ABS board,stones and imitation stones as well as metallic molds like an aluminum mould,and others.
ANY QUESTIONS,YOU CAN CONTACT"
