Specifications
1.Power:110Watts2.Size:482*370*88mm
3.Output Mode:70V/100V/4-16ohm
4.N.W:7.0KG
Features:
2 MIC inputs , 2AUX input ,1AUX output,MIC1 has priority (mute function ).
Power outputs: 4-16 Ω,70V,100V,3 zones output.
Individual control for MIC and AUX input.
With MP3 player,support MP3 and WMA.USB,,SD and FM.
Bass control , Treble control.
Protection for overload and short circuit.
Specifications:
Model | SGP-U70A | SGP-U110A | |
Rated Output Power | 70W | 110W | |
Power Outputs | 4-16Ω,70V,100V | ||
Frequency Response | 40Hz-18KHz±0.5dB | ||
S/n Ratio | MIC part>70dB,AUX part>76dB | ||
Tone | Bass: ±10dB at 100Hz Treble: ±10dB at 100Hz | ||
Power Requirements | AC 220V(50-60Hz) | ||
Dimensions | 482×310×88mm | ||
Weight | N.W:7.0Kg | N.W:8.0Kg | |
Packing Size | 52×44×18CM | ||
Note
1)AC220(50Hz-60Hz)
2)Don't put the vents to avoid emission effect.
3)To avoid unnecessary overload and short circuit.
4)When play MP3,If MIC and circuit are not used,Pls put off the knob.
5)When the machine is abnormal, Non-professional persons .Do not open and
maintain it, to avoid electric shock accidents.
