Home > Products > Automatic Inner Laminating Machine > ZTC-900B Automatic Adhesive Machine
ZTC-900B Automatic Adhesive Machine
- 15 Set / Sets per Month
- Shanghai or Ningbo
- T/T Credit Card PayPal
- Inside and outside bag packaging line Healthy teatriangle packaging linkage line
- Pharmaceuticals industrypackaging assembly line Packaging production line
- China teatriangle packaging linkage line Green teainternal and external package linkage line
- Packing and palletizing linkage line Beverage industrybox and palletizing production line
- Pharmaceuticals industrypackaging linkage line Packaging production line
- Box code stack production line Beverage industrybox and palletizing assembly line
Product Details
Condition: | New | Application: | Other, Machinery & Hardware | Packaging Type: | Case |
Packaging Material: | Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 14KW | Place of Origin: | Zhejiang, China |
Brand Name: | KEQIANG | Model Number: | ZTC-900B | Dimension(L*W*H): | 7500 X 2600 X 1500mm |
Weight: | 2500kg | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
ZTC-900B Automatic Adhesive Machine
1.The unique double sheets detection system avoids and solves the problem of two or more paper feeding.
2.Automatic photo sensor correction positioning system enhances the lamination accuracy of board and paper.
3.The multi circulation board feeding enhances the board changing efficiency greatly.
4.The special cam mechanism makes the machine performance more stable and reliable.
5.The touch screen operation menu and machine fault display function make the operation more convenient.
6.Stable and reliable mechanical drive structure, high quality electrical components ensure the machine performance.
Main Specification
Model | ZTC-900B |
Maximum Size | 450mm×900mm |
Minimum Size | 140mm×190mm |
Board Thickness | 1.0-3.0mm |
Paper Weight | 105-210g |
Maximum Speed | 20-30picecs/min |
Power Supply | 14Kw/380V |
Dimension(L×W×H) | 7500×2600×1500mm |
Machine Weight | 2500kg |
Position Accuracy | ±1mm |
Process Flow:
Each Part
