Poly foam Processing CNC Machine for Cutting and Engraving
Model: CC-B1224B Certificates: CE,IS090001:20000
Applicable materials:
Wood, EPS and non-metallic materials.
1. Mold industries:
sculpture various large non-metallic mold can be particularly suitable for any kind of Foam
(EPS) mould, wooden ship model,wooden model aviation and other wooden mould.
2.Musical instrument industry: Can carve three dimension musical instrument,contour cutting.
Processing effect:
It can manufacture the following effects: engraving, cutting, milling ,drilling, relief, shadow,
enchasement and so on.
Features:
1. CC-B1325B Mold machine's effective working area is 1300mm*2500mm*500mm(XYZ).
2. Heavy Hard Steel Lath Body, keep the machine's working High stability.Whole machine is welded
with seamless steel structure, dealing with Time-treatment, the stability is excellent, never to be deformed.
3. Germany high-precision and bigger ball screw. Original Bigger Taiwan HIWIN Straight Square
Guide Rail. To make sure the machine’s working high-speed and high-efficiency.
4. The machine adopts gantry movement , it can process any kinds of materials freely.
5. Well compatibility: CAD/DAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
7. Has the function of recarving after break point and power failure.
8. Has the function of forecasting process time.
9. DSP control system can completely work off-line and do not take any computer resources.
10. Perfect oil-inject system makes maintenance much easier.
11.Tools' Specification: You can choose different diameter and length tool according to your processing .
PARAMETERS
Model |
CC-B1224B |
Lathe body |
Thick and Hard Steel structure (sand blast & seasoning) |
X Y effective working area |
1200*2400*500mm |
Precision Machining |
0.1mm/1000mm |
Max Traverse Speed |
30000mm/min |
Max processing speed |
20000mm/min |
Table size |
1300*2700mm |
Resolution |
0.01—0.03 mm |
Spindle power rate |
4.5kw Water cooling spindle |
Inverter |
FULING |
X,Y structure |
Rack and pinion transmission, Taiwan-made Linear Bigger orbit |
Z structure |
Germany-made ball screw |
Guide Rail |
Hiwin |
Spindle rotating speed |
0-24000r/min |
Standard Power |
AC380V-/220V-Three Phase (Optional) |
Max. idling speed |
30000mm/min |
Cooling mode |
Water-cooling |
Command |
G code,HPGL,U00,mmg,plt |
Dust-collect function |
Yes |
Clamping mode |
By Slots |
Operating system |
DSP system |
Diameter of cutter |
φ3.175-φ20 |
Working mode |
STEPPER |
Spare Parts:
Side Picture of CC-BS1224B Model Foam CNC Machine
Wooden sample made by CC-BS1224B Model Foam CNC Machine
Samples:
Certificates:
For any questions, please contact:
SKYPE:saracnc85
