CHENCAN 4Axis 3D Foam/Wood Mould Carving CNC Machine CNC Router with 4th Rotary
Applicable industries:
Mould industry: It engraves all kinds of large nonmetallic moulds; especially automotive foam mould, wooden ships mould, aviation and train wood moulds. And wood mould casting, food mould (such as moon cake mold) and other precision mould making.
Features:
MOULD MAKING CNC ROUTER/MOULD CNC MACHINE/FOAM MOULD CUTTING /WOOD MOULD
1. Lathe bed is welded with thicker square tube and is processed by high temperature tempering treatment and vibrating stress relief (VSR) to relief residual stress. The stability is excellent, not easy to be deformed. It has the property of good rigidity and heavy loading.
2. Four-row imported ball bearing, widening linear guide rail, self-lubricating sliding block. When engraving, equal force in all directions, to ensure the accuracy and strength.
3.Three axes of the mould cnc router adopt Hiwin high precision square guide rail; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost; Z axis adopts Germany-made ball screw, with high precision and longevity.
4. Z axis can be heightened to 1,000 mm, suitable for large-scale material 3D curve working. MOULD MAKING CNC ROUTER/MOULD CNC MACHINE/FOAM MOULD CUTTING /WOOD MOULD
5. Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Castmate/Wentai etc.
6. Has the function of re-carving after break point and power failure.
7. Has the function of forecasting process time.
8. Intelligent processing cross-border protection function can prevent mechanical impact caused by the improper design documents.
9. Diversified control system of the mould cnc router can control processing speed, idling speed and tool falling speed respectively, greatly improved the quality of processed products and processing efficiency.MOULD MAKING CNC ROUTER/MOULD CNC MACHINE/FOAM MOULD CUTTING /WOOD MOULD
Spare Parts:
Samples:
Parameter:
MOULD MAKING CNC ROUTER/MOULD CNC MACHINE/FOAM MOULD CUTTING /WOOD MOULD
Description |
Parameter |
X,Y Working Area |
2000×4000mm |
Z Working Area |
1000mm |
Resolution |
0.05mm |
Repositioning Accuracy |
0.05mm |
Lathe Structure |
Seamless welded steel structure, better than cast iron one |
X,Y Structure |
Rack and pinion transmission, Hiwin square guide rail |
Z Structure |
Germany-made rolling ball screw, Hiwin square guide rail |
Max. Idling Speed |
30m/min |
Spindle |
iTALY HSD 9KW TOOL CHANGING |
Spindle Rotate Speed |
0-24000r/min, variable speed |
Working Voltage |
AC380V/50Hz |
Working Mode |
JAPAN SERVO MOTOR |
Command |
G code (HPGL,U00,mmg,plt) |
Operating System |
taiwan syntec |
Diameter of cutter |
φ3.175-φ16mm |
Cooling Mode |
AIR-cooling |
Work-holding |
By clamp |
Net Weight |
3000KGS |
Software |
Type 3, ArtCam, Ucancam |
Certificaed & Delivery:
For any questions, please cotact:
