Specifications
3mm round pure green diffused dip LEDgreen color
3.0-3.4v
4500mcd
* The LED chip material is gallium phosphide
* Different colors and luminous intensity are available for this LED lamp.
Product Advantages
1. Good raw materials used
2. Super luminous efficiency
3. Low brightness decay
4. High quality with RoHS , Reach certifications
5. 99.99% purity golden wire used
6. Packaging: Moisture proof, dust free, anti-static
Application
1. TV set
2. Monitor
3. computer
4. Ect
Absolute Maximum Ratings at Ta=25°C
Parameter |
Symbol |
Value |
Unit |
Power dissipation |
Pd |
120 |
mW |
DC Forward Current |
If |
30 |
mA |
Peak Forward Current(1) |
Ifp |
100 |
mA |
Operating Temperature |
Topr |
-25to+85 |
°C |
Storage Temperature |
Tstg |
-40to+100 |
°C |
Lead Solder Temperature(2) |
Tsol |
260 for 5sec |
°C |
Notes:
1. 1/10 duty cycle, 0.1 ms pulse width;
2. 2mmbelow package base.
Electrical/Optical Characteristics Ta=25°C
Parameter |
Symbol |
Condition |
Value |
Unit |
||
Min. |
Typ. |
Max. |
||||
Forward voltage |
Vf |
If=20mA |
3.0 |
3.2 |
3.4 |
V |
Luminous intensity |
Iv |
If=20mA |
--- |
4500 |
--- |
mcd |
Dominant wavelength |
λd |
If=20mA |
523 |
527 |
--- |
nm |
Peak wavelength |
λp |
If=20mA |
515 |
520 |
--- |
nm |
Spectral Line half-width |
Δλ |
If=20mA |
--- |
20 |
--- |
nm |
Reverse current |
Ir |
Vr=5V |
--- |
--- |
10 |
μA |
Notes:
1. Forward Voltage:±0.1V;
2. Color temperature: ±5%;
3. Luminous intensity: ±10%.
Other Available Products
1. 3mm/5mm/10mm round series; 3mm/5mm bi-color series; 3mm/5mm straw hat series
2. 5050,3528,2835,5054 SMD LED
3. 1w/3w high power series
