365nm DIP Encapsulation UV LED for Money Detector

365nm DIP Encapsulation UV LED for Money Detector thumbnail-1
365nm DIP Encapsulation UV LED for Money Detector photo-1
US$ 0.46 - 0.55 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
WEJ
Model Number:
WEJ324PC-D90
Contact Supplier Request Quote Chat Now
Shenzhen Yongerjia Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name WEJ
Model Number WEJ324PC-D90
Type LED
Package Type Through Hole
Max. Forward Voltage 3.6V
Max. Reverse Voltage 5V
Max. Forward Current 20mA
Max. Reverse Current 10uA

Specifications

365nm DIP Encapsulation UV LED for Money Detector
1.Wavelength: 365-370nm
2.Optical power:10mW
3.RoHS,REACH compliant

365nm DIP Encapsulation UV LED for Money Detector





Features of 365nm UV LED:

*Low power consumption

*Long life-solid state reliability

*Available on reel

*RoHS REACH compliant

*Emitted Color: UV 365-370nm

*Viewing Angle:15 degree





Specification of 365nm UV LED:

Parameter

Symbol

Min.

Typ.

Max.

Unit

Test Condition

Luminous power

Φ

8



15

mW

IF = 20mA

Viewing Angle

2θ1/2

---

15

---

deg

IF = 20mA

Wavelength

   WD

-365-



--370-

nm

IF = 20mA

Forward Voltage

VF

2.8

---

3.6

V

IF = 20mA

Reverse Current

IR

---

---

5

uA

VR=5V



Package outline dimensions of 3mm UV LED:

365nm DIP Encapsulation UV LED for Money Detector

Note:

1.All dimensions are in millimeters (mm);

2.Tolerance is +/-0.25mm unless otherwise noted;

3.Lead spacing is measured where the leads emerge from the package.



365nm DIP Encapsulation UV LED for Money Detector365nm DIP Encapsulation UV LED for Money Detector



Application of 365nm UV LED:



365nm DIP Encapsulation UV LED for Money Detector

WEJ Factory:

365nm DIP Encapsulation UV LED for Money Detector



We promise:

 1. Your inquiry will be replied within 24 hours

 2. Pack the goods very well and delivery them as soon as possible

 3. Protection of your sales area, ideas of design and all your private information

 4. Get in touch with us if you have any requirements. We also produce various kinds of LED SMD, such as 3014, 2835, 3528, 5630, 5050, etc.

 5. We will try our best to solve the problems within or out of the warranty time.
