Home > Electrical & Electronics > Electronic Tube & Transistor > Rectifier Diode > 3mm Round Amber Diffused Dip LED

3mm Round Amber Diffused Dip LED

US$ 0.018 - 0.021 MOQ: 20000 Pieces

Key Specifications

Get Latest Price

Brand Name:

WEJ

Model Number:

WEJ324OD-901-1

Type:

LED

Contact Supplier Request Quote Chat Now

Shenzhen Yongerjia Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name WEJ

Model Number WEJ324OD-901-1

Type LED

Package Type Through Hole

Max. Forward Voltage 2.4v

Max. Forward Current 30mA

Max. Reverse Current 10uA

Specifications

3mm round amber diffused dip LED
Amber diffused
1.8-2.4v
40-80mcd

Product Description

Different colors and luminous intensity are available for this LED lamp.

Product Advantages

1. Good raw materials used

2. Super luminous efficiency

3. Low brightness decay

4. High quality with RoHS , Reach certifications

5. 99.99% purity golden wire used

6. Packaging: Moisture proof, dust free, anti-static

Application

1. Electronic toy

2. Electronic indicator

3. Electronic display

4. Etc

Absolute Maximum Ratings at Ta=25°C

Parameter	Symbol	Value	Unit
Power dissipation	Pd	72	mW
DC Forward Current	If	30	mA
Peak Forward Current⁽¹⁾	Ifp	100	mA
Operating Temperature	Topr	-25to+85	°C
Storage Temperature	Tstg	-40to+100	°C
Lead Solder Temperature⁽²⁾	Tsol	260	°C

Notes:

1. 1/10 duty cycle, 0.1 ms pulse width;

2. 2mmbelow package base.

Electrical/Optical Characteristics Ta=25°C

Parameter	Symbol	Condition	Value			Unit
Parameter	Symbol	Condition	Min.	Typ.	Max.	Unit
Forward voltage	Vf	If=20mA	1.8	2.1	2.4	V
Luminous intensity	Iv	If=20mA	40	60	80	mcd
Dominant wavelength	λd	If=20mA	600	605	610	nm
Peak wavelength	λp	If=20mA	605	610	615	nm
Spectral Line half-width	Δλ	If=20mA	---	20	---	nm
Reverse current	Ir	Vr=5V	---	---	10	μA
