Specifications
The machine is with good quality,best price and good after-sale service.This machine is three roller symmetrical, the upper roller is running vertically in the center symmetrical
position of the two lower rollers, the two lower rollers rotating running, by the output gear of the reducer,
it engaged with the lower roller’s gear, to provide the torque for the rolled plate.
Max. rolling thickness |
20 | mm |
Max. Rolling width |
2000 | mm |
Min. Diameter while full load |
700 | mm |
Yield strength of the rolled plate |
245 | Mpa |
Diameter of upper roller |
280 | mm |
Diameter of lower roller |
250 | mm |
Central distance of lower rollers |
360 | mm |
Main driving motor power |
11 | KW |
Electric control system
Motive power: 380V/50Hz. The main switch has the short-circuit protection function and overload protection function. The motor’s positive and negative running is
controlled by current connector; there are control button and indicator in the electric box, to control the
operating and working for the whole during working.
Within 30 working days after payment.
It equip with front support material device and it is convenient to store and transport.
1.After finished the producing of the machine, we will inform the buyer to inspect the machine in the manufacture’s factory.
2.We provide some documents and foundation drawing within 7 days after contract date.
3.If need seller to guidance the installation, adjustment and trial, the seller is responsible for the charges within home, and
other charges on board should be paid by the buyer.
Zhongwei has forty years company history,it recorded the glorious development of shearing,press and rolling machine.Zhongwei
is located in globals economically developed Changjiang Delta.It is east to Yellow Sea,south lean on Changjiang River,west to
Ningyang and north to Yanfu,the superior geographical advantages supply the company’s development with good element.
Zhongwei is bursting out of the booming energy,ranked the top 30 largest taxpayer,we won the “national high and new
technology enterprise”.Our company has participated in the Carton Fair for many times, meet ing friends from all around the world, and exported machines to the United States, India, Russia, Mexico, Vietnam and so on.
