Specifications
Metal Plate Cutting Machine1.Certificate ISO
2.Option Ball screw
3.Option SNC,DELEM
4.Protective Guard
QC11K-6X3000 metal sheet hydraulic shearing guillotine type machine metal sheet hydraulic shearing guillotine type machine
Shear Machine
Hydraulic Shear Machine
Main electric elements:Siemens
Throw pill machine to eliminate the residual stress
Annealing Oven to improve the properties of steels
Metal Plate Cutting Machine QC11Y-6*5000
Features
1.Hydraulic individual sheet material clamping system with nylon inserts to protect material from indentation from the clamping cylinders along full length of machine.
2.Hydraulic adjustable variable rake 0.5° - 2° (shearing angle) via push buttons on Control box with angle light indicating selected position.
3.Control box mounted higher than standard on side of machine to protect it from material damaging the control unit due to heavy material loading on sheet supports prior shearing.
4.Simplified blade gap adjustments to allow for a wide range of material types and thicknesses of 0.5 - 8mm enabling minimised distortion of the cut length.
5.Transfer balls inserted into work table allowing material to be easily moved to the cut position and squaring arm.
6.Top shearing blade made from Inox quality composite and has two (2) cutting edges allowing minimised down time in blade rotation.
7.Bottom shearing blade made from Inox quality composite and has four (4) cutting edges allowing minimised down time in blade rotation.
8.The core structure of the steel main frame has been electronically welded ensuring maximum penetration during the manufacturing process. In addition to this feature the cutting beam has been stress relieved eliminating any distortion after manufacturing.
9.Shadow line lighting has been incorporated into the machine frame providing a clear cutting line on the work piece and enabling scribed or marked material to be cut with simplicity as required.
