Product Details
Place of Origin: | Jiangsu, China | Brand Name: | zhong wei | Model Number: | QC11Y-25*3200 |
Product Description
Specifications
This machine is suitable for shearing the plate that the thickness is 1.0-25mm, width<3200 mm, The strength of sheets is 450N/mm2. Main technical data
No | Name | Data | Unit | Remarks | |
1 | Max thickness of cutting plate | 25 | mm |
| |
2 | Max width of cutting plate | 3200 | mm |
| |
3 | Strength of cutting plate | 450 | N/mm2 |
| |
4 | Cutting angle | 2°20′ |
|
| |
5 | Number of stroke | 12 | min-1 |
| |
6 | The distance of two columns | 2765 | mm |
| |
7 | Length of blade | 2600 | mm |
| |
8 | The height of working table | 815 | mm |
| |
9 |
Main motor | Type | Y200L2-6 |
| B5 |
Power | 22 | kW |
| ||
Speed | 960 | r/min |
| ||
10 |
Backgauge motor | Type | Y80M2-6 |
|
|
power | 0.55 | kW |
| ||
Speed | 900 | r/min |
| ||
11 |
Axial pump | Type | 63MCY14-1B |
|
|
Speed | 63 | L / min |
| ||
Pressure | 31.5 | MPa |
| ||
12 |
Outside size | Length | 3200 | mm |
|
Width | 2100 | mm |
| ||
Height | 1930 | mm |
|
