3/4lamps Led Module (CE,RoHS)with Smd 3528 /5050$single Color

3/4lamps Led Module (CE,RoHS)with Smd 3528 /5050$single Color thumbnail-1
3/4lamps Led Module (CE,RoHS)with Smd 3528 /5050$single Color photo-1
US$ 0.2 - 2 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Model Number:
SJ-3535-ICRGB ws2801
Chip Material:
Other, Epistar
Emitting Color:
Warm White
Contact Supplier Request Quote Chat Now
Shenzhen Centuryled Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen yantian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number SJ-3535-ICRGB ws2801
Chip Material Other, Epistar
Emitting Color Warm White
Luminous Intensity 6500
Luminous Flux(lm) 16-19lm
Optical Attenuation(%) 0.3%
Power Other, 0.96, 0.96W
Power Dissipation 0.5%
Color Rendering Index(Ra) 85
Color Temperature rgb
Operating Temperature(℃) -40, 60
Storage Temperature(℃) -20, 60
Place of Origin Guangdong, China
Brand Name SJ
Certification CE

Specifications

1 epistar
2 factory direct price
3 ws2801 chip
4 2years warranty



 ws2801 pixel square led module


 description:

Ø Superbright SMD top LED & viewing angle, high brightness output, no spot and shadow.
Ø Colors can be chosen as Full color, and the lumen is R:3/G:9.6/B:2.4lm.
Ø Low power consumption & operating voltage, safe and energy-saving.
Ø With IP65 protection rating.
Ø Solid-state, high shock or vibration resistant, long lifetime, more than 50000 hours.
Ø Easy installation with mounting holes and 3M adhesive tape on the back.
Ø CE & Rohs 5050 smd led controller flashing module ic chip
Features:
4 leds ws2801 rgb pixel led backlight module
l   individually Control
l   Programable & SD controller
l   DMX 512 Controllalbe
l   Madrix compatible
l   IP66, Water-proof protection
l   Easy installation (two options: screw fixed, or 3M double side adhesive tape)
|   20pcs per string, 8cm spacing apart ,metal case
|   3535 size 4pcs 5050 leds ws2801 rgb pixel led backlight module, arduino
datasheet

Model NO.

SJ-3535-2801

IC chip

WS2801

Power Consumption

0.96W

Work Voltage

DC 12V

Beam Angle

≥120

LED Quantity

4 PCS SMD 5050

Color

Full color (ICRGB)

Dimension

36*36*4mm

Waterproof Grade

IP66

Work Temperature

-40-+60°C

Life-span

50,000H

Certificate

CE&RoHS

Warranty

2 years

Details

3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color


 3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color



3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color



3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color



3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color





3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color









3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color














Payments
  • L/C
  • T/T
  • Western Union
  • MoneyGram



  1. Goods will be delivered within 3-5 working days after the payment received
  2. We ship item via Door to Door service express or air and sea.



Packing







Project





 3/4lamps led module (CE,RoHS)with smd 3528 /5050$single color
