Specifications
It is used in leveling the cool plate of bending deflection.It makes the plate even ,smooth and level .It is easy to use and maiNo. |
Item |
Unit |
data/function |
1, |
Max.straight thickness |
mm |
36 |
2, |
Min.straight thickness |
mm |
9 |
3, |
Max.straight width |
mm |
3500 |
4, |
Yield strength of the plate |
MPa |
composite board |
5, |
Quantity of rollers |
rollers |
7 |
6, |
Diamiter of roller |
mm |
Φ390 |
7, |
Distance of roller |
mm |
520 |
8, |
Material of roller |
|
40CrMo |
9, |
effective length of roller |
mm |
3600 |
10, |
Diameter of supporting roller |
mm |
Φ390 |
11, |
Supporting roller |
set |
5 |
12, |
Material of supporting roller |
|
40Cr |
13, |
Leveling speed |
m/min |
5m/min |
14, |
Power of main motor |
KW |
144 |
15, |
Power of screwdown motor |
KW |
2*22 |
16, |
Leveling precision |
mm/m2 |
≤1.5(Q235) |
17, |
Displacement display (digital display) |
KOYOSEIKO Japan It shows upper roller’s movement,correct to 0.1mm. memory store when power off. |
|
18, |
PLC |
Mitsubishi Japan |
|
19, |
Lubrication system |
Bijur Nanjing |
|
20, |
Low-voltage apparatus |
Siemens Suzhou |
|
