maquina para carpinteria, cnc router 1325 automatic tool changer,cnc 1325 wood cutting machine DT1325ATC
- Qingdao port China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
1325 automatic tool changer, cnc router automatic tool changer,cnc 1325 wood cutting machine DT1325ATC
-
cnc router atc lathe, woodworking atc cnc router,act woodworking machine DT1325ATC
-
cnc router atc japan,cnc router with atc,auto tool changer cnc router DT2060ATC
-
multicut and atc cnc router, cnc wood carving machine, cnc engravig machine for woodworking DT2060ATC
-
cnc router atc lathe, cnc wood carving machine, cnc engravig machine for woodworking DT2060ATC
-
cnc router atc japan, cnc wood carving machine, cnc engravig machine for woodworking DT2060ATC
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | DragonTech | |
| Model Number | DT1325ATC | Voltage | 380V/3ph | |
| Power(W) | 13kw | Dimension(L*W*H) | 1300*2500*200mm | |
| Weight | 1500 | Certification | CE | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
In wooden case
Product Description
maquina para carpinteria, cnc router 1325 automatic tool changer,cnc 1325 wood cutting machine DT1325ATC
Applications:
Dragon Tech ATC CNC Router is suitable for hard wood-working, cutting and engraving on rosewood for furniture, indoor decoration, MDF, and so on, with high speed and high precision.
Options:
Diving system:stepper system, Panasonic/Yaskawa/Delta servo system
Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle
Inverter: Delta inverter,Fuling inverter
Control system: DSP, Mach3, Ncstudio, Syntec
Vacuum pump: Germany Becker pump, Chinese pump
Can equip rotating axis, lubricating system, mist cooling system and so on.
No. |
| Description |
| DT1325ATC |
1 |
| X,Y,Z working size |
| 1300*2500*200mm |
2 |
| Working table |
| Vacuum and T-slot aluminum |
3 |
| Gantry |
| Steel gantry |
4 |
| Lathe structure |
| Welding steel tube frame |
5 |
| Transmission system |
| Rack pinion for X/Y, Ball screw for Z; HIWIN linear Rails for X/Y/Z |
6 |
| Driving system |
| Panasonic servo system |
7 |
| Repositioning accuracy |
| ±0.03mm |
8 |
| Max. travelling speed |
| 50000mm/min |
9 |
| Max. working speed |
| 25000mm/min |
10 |
| Spindle and collet |
| 9kw HSD spindle,ER32 |
11 |
| Spindle speed |
| 0-24000RPM |
12 |
| Working voltage |
| AC380V/3ph |
13 |
| Max. consume power |
| 13kw |
14 |
| Operating system |
| Syntec |
15 |
| Command code |
| G code(*uoo, *nc, *mmg, *plt) |
P.S.
All the parts of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on
