Specifications
1. Lower power consumption2. Automatic Operation
3. Widely application
Flake Ice Machine KP5
-1. Flake ice
Flake ice is made of the fresh water , in some cases can be directly made from brine water. Thickness between 1.8mm to 2.2 mm, irregular shape with diameters from 12 mm to 45 mm.
Flake ice is thin and dry, without any edges and corners, which can not hurt chilled food.
-2. Evaporator
The evaporator of the flake ice machine is a vertically placed drumshape stainless steel container, equipped with the rotating blade which spins and scratches the ice of the inner wall of evaporative. When operating, the principal shaft and blade spins anticlockwise pushed by the reducer. Water is sprayed down from the sprinkler; ice is formed from the water brain on the inner wall.
-3. . Microcomputer intelligent control:
The machine is using PLC control system with world famous brand components, which control the whole ice making process, meanwhile it can protect the machine when there are water shortage, ice full, high /low pressure alarm, and motor reversal in order to guarantee the machine run stably with less faults.
-4. The main components of the flake ice machine.
-5. Application:
5.1 Brinewater flake ice machine can make ice directly from the sea water. This ice can be used in fast cooling of fish and other sea products. The fishing industry is the largest user of flake ice machines. Flake ice can lower the temperature of cleaning water and sea products, therefore it resists the growth of bacteria and keeps the seafood fresh.
5.2 . Because of its large contact and less damage with refrigerated materials, it is also applied in vegetable, fruit and meat storing and transporting.
5.3 In most cases of biosynthesis and chemosynthesis, flake ice is used to control the reaction rate and maintain the liveness. Flake ice is sanitary, clean with rapid temperature reduction effect.
5.4 Flake ice is used as the direct source of water in concrete cooling process, more than 80% in weight. Concrete will not crack if has been mixed and poured in constant and low temperature.
1. Emergency Alarm: It makes you know immediately once the emergency happens
2. Cable Channel: All the wires packed in stainless steel channel, protects the wire, also makes the machine look neat and tidy
3. Energy Guide: You can see clearly the energy consumption of the machine
Flake Ice Machine with Stainless Steel 304
Flake Ice: Dry, pure, powder-less, not easy to block, without edges or corners which will can product the coolig food, fish, seafood adn other products.
Evaporator Drum: Use stainless steel 304 or carbon steel chrominum. The scartch-style system of inside machine ensures constant running at the lowest power comsumption, exquisite welding and processing technology ensure high-efficent heat transfer and energy saving.
Stainless Steel 304 Evaporator Drum
Layout of flake ice machine with Ice storage
Brand Name Accessories
Warranty: 12 months after the delivery; During the warranty periods, if there is any malfuction, we would try our best to solve the problem at our fastest speed. If some spare parts are needed to be replaced without artificial damage, then we would provide the spare parts free of charge. We also provide the life long technical support.
Installation:
1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts operation manual and CD are provided to guide the installation.
2). Installing by Koller engineers:
(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.
(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.
(3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.
(4) 2~ 3 workers are required to assist the installation for big project.
(5) Any delay due to customer’s reason, it will be charged from the 8th day, USD100/day for one person as installation fee. Free of charge for one week.
Koller specialize in ice machine research, design, manufacture for 10 years since 2004, our products sell all over the world, and you can see many refrigeration equipments in your daily life, we produce block ice machine, tube ice machine , cube ice machine, plate ice machine , flake ice machine and cold room. Koller is one of biggest ice machine producer in China, you can buy different kinds of ice machine from us for different applications.
