Specifications
Tube Ice Machine1.Crystal edible cylinder ice
2.PLC control system
3.Bitzer compressor
4.For bars and restaurants
Koller Commercial Tube Ice Machine with PLC Controller (2000kg/day)
1. Product Features
1). Harvest ice way: Hot gas defrosts;
2). Ice tube Size: 20mm, 28mm, 34mm or 40mm in diameter; 30mm~50mm in length.
Cylinder tube ice
3). Evaporator: tube vessel, its top and bottom part was welded with quality joining.
4). PLC program Logic Controller, which allows multiple functions such as automatic machine start and shut down; ice falling automatically when the freezing time is ensured, Automatic water making up.
5). Rotating Driver Ice Cutter: stainless steel 304 Ice Cutter Blade run by medium speed gear motor.
6). Special ice outlet. Ice discharging automatically, No need taking ice by hand which can guarantee the ice clean and sanitary.
2. Main Components
Item |
Name of Components |
Brand Name |
Original Country |
1 |
Compressor |
BITZER/COPELAND |
Germany/USA |
2 |
Ice Maker Evaporator Grid |
KOLLER |
China |
3 |
Water cooled condenser |
KOLLER |
|
4 |
Refrigeration components |
DANFOSS/CASTAL |
Denmark/Italy |
5 |
PLC Program control |
SIEMENS |
Germany |
6 |
Electrical components |
LG (LS) |
South Korea |
3. Tube ice machine TV20: 1550mm*910mm*2010mm ;
TV20 ice tube machine with water cooled system
Cooling tower
TV20 ice tube machine with air cooled system
4. Supply Power Form: 380~420V, 50Hz, 3P or 220~240V, 60Hz, 3P.
5. Cooling System: Water or air cooled system.
6. Installation: The machine has been installed and tested before delivery, only needs customer to connect water pipes and power, the accessory spared parts are offered free of charge.
