KOLLER CV Series Ice Cube Machine
1,
2. CV3000 ice cube machine is made up of: 1 piece of cube ice maker part, 1 piece of cooling tower, water pumps, water pipes, and other accessories.
3. Packing: in plywood case for cube ice machinery units, cooling tower and other parts are loaded by C.K.D.
4. Terms of Payment: T/T. 50% of total value as advanced payment, the 50% balance should be paid before shipping.
5. Installation: We will test and install the machine before shipping; you need to be ready for connecting the water pipes and power. The operation manual and CD are provided to guide the installation. Meanwhile, if the buyer needs us to send engineer for installation in your place, the buyer affords the tickets, accommodation and food for the engineer, free of charge within 5 days for installation.
6. Warranty period: 12 months for the machine after delivery. The spare parts are provided with machine free of charge.Once the machine is out of work, you can send us pictures or video about the fault, we will mail you the solution to solve problems within 24 hours. Or we also can send one engineer to your place for door to door service. If the parts is broken and proved by our engineer for non-personal reason, we will offer free parts to replace within guarantee period; if it is beyond guarantee period, we will charge market price for the new parts.
2. Specification of cube ice |
Ice Cube Size |
Ice freezing time |
Production |
29mm*29mm*22mm |
Every 23 minutes |
42 kg/shift; 125 kg/hour |
22mm*22mm*22mm |
Every 20 minutes |
48 kg/shift; 125kg/hour |
3. Working environment |
|
1. Max. Ambient temp. |
+40℃ |
2.Max relative humidity |
85% |
3.Supply water temp |
21℃ |
4.Condenser temp |
40℃ |
5. Evaporating temp. |
-15℃ |
6.Power supply |
380V 3P 50Hz, / 220v 3P 60Hz |
7.Refrigerant |
R404a, will not damage Ozono |
8.Compressor type |
Semi-hermetic piston compressor |
9.Cooling system |
Water cooling condenser |
4. Basic parameter |
|
No. |
Name |
Technical Data |
|
1 |
Daily capacity |
3 tons/24h |
|
2 |
Material for framework |
Stainless steel 304 |
|
3 |
Material for ice maker grids |
Stainless steel 304 |
|
4 |
Compressor |
Brand name |
Semi-hermetic, BITZER/Copeland/Bock |
Horse power |
14 HP (10.5 KW) |
||
Quantity |
1 set |
||
5 |
Cooling tower |
Cooling water flow |
19.5m³/h |
Air flow |
200 CMM |
||
|
5
|
Measurement
|
Machinery unit |
1700mm(L)*1230mm(W)*1970 mm(H) |
Cooling tower |
1270mm(L)*1270mm(W)*1470mm(H) |
||
Power issues | |||
1 |
Compressor |
10.5 KW |
|
2 |
Circulated water pump |
0.55 KW |
|
3 |
Cooling water pump power |
1.1 KW |
|
4 |
Ice discharging motor |
0.75 KW |
|
5 |
Cooling fan motor |
1.1 KW |
|
|
Power consumption: 80~85 KW*H making 1Ton ice; Water consumption: 1.1 Ton water can make 1Ton ice. | |||
Note:The above data is just for your reference and is subjected to final design.
