EGBO3 18-36KW Wall Mounted Gas Boiler for Shower and Floor Heating

EGBO3 18-36KW Wall Mounted Gas Boiler for Shower and Floor Heating photo-1
EGBO3 18-36KW Wall Mounted Gas Boiler for Shower and Floor Heating photo-2
EGBO3 18-36KW Wall Mounted Gas Boiler for Shower and Floor Heating photo-3
US$ 230 - 230 MOQ: 200 Units
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Other, Home
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Natural Circulation
Usage Other, Home
Structure Water Tube
Pressure Low Pressure
Style Vertical
Fuel Gas-fired
Place of Origin Guangdong, China
Brand Name EAGLEON
Model Number EGBO3
Output Hot Water
Dimension(L*W*H) Requirement
Weight 30kgs
Certification ISO9001
After-sales Service Provided No overseas service provided

Wall mounted Gas Boiler for water heater and floor heating

Model No.: EGBO3









Gas Boiler specification
Model T 16 kW 20 kW 24 kW
Gas Type T G20 G20 G20
Rated Gas Pressure Pa 2000 2000 2000
Rated Heat Input kW 18.12 22.06 26.37
Rated Heat Output kW 16.6 20.34 24.49
Efficiency Grade % 90-91% 90-91% 90-91%
Max. Input DHW kW 18 21.65 26.07
Max. Output DHW kW 16.2 19.51 23.7
Min. Input DHW kW 7.8 9.5 12.71
Min. Output DHW kW 7 8.55 11.49
Floor Heating Max. Heating Temp. 80 80 80
Water Temp. Range (±3) Radiator:30-80 Radiator:30-80 Radiator:30-80
Max. Water Pressure MPa 0.3 0.3 0.3
Expansion Tank Capacity L 6 6 6
Preset Pressure,Expansion Tank  MPa 0.1 0.1 0.1
Water Heating Rated Water Production  ^t=30k L/Min 7.1 9.21 11.18
Water Temp. Range(±3) 30-60 30-60 30-60
Water Pressure Range MPa 0.03-0.6 0.03-0.6 0.03-0.6
Min. Hot Water Flow  L/Min 3 3 3
Water Flow Limit L/Min 7.3 9 10
Power Supply V/Hz 220V 50Hz 220V 50Hz 220V 50Hz
Rated Power W 105 105 105
Insulation Grade G
Protection Grade G IPX4 IPX4 IPX4
Pipe Connection Gas Inlet mm G3/4" G3/4" G3/4"
CHW Inlet/Outlet mm G3/4" G3/4" G3/4"
DHW Inlet/Outlet mm G1/2" G1/2" G1/2"
Air Input/Exhaust Duct mm φ100/φ60 φ100/φ60 φ100/φ60
Pump Lift M 5 5 5
Dimension(L*W*H) mm 740*400*255 740*400*295 740*400*295
Packing mm 830*480*355 830*480*390 830*480*390
Loading qty (20GP/40HQ) pcs 200/490 165/430 165/430





 Inner Strucure and Parts :
