Specifications
1.Min. Order: 1 Set2.FOB Price: negotiable
3.Payment Terms: L/C,D/P,T/T,Western Union
4.Supply Ability: 50 Sets per month
Cold Room VCR10
Design
KOLLER Modual Cold Room (0- -20 Degree Celsius)/Cold Room/Cold storage room/Storage Room has different capacity, it can be made according to your requirements. It has the door so that you can storaget hings very conveniently. it is for a integrated refrigeration system.
Temperature
the temperature can be adjusted from 0 degree celsius to -25 degree. To meet the needs to store ice, we design -12 degree cold room temperature.
Pratctical
This Modual Cold Room can storage food, fruit, fish, ice etc. The temp can be designed at any state.
Capacity
It is for 10CBM to 400CBM . the size can be designed like a container.
It can admit from 5tons to 100 tons for different foods.
Cold Room VCR10 Specification:
Cold Room Size: 2500mm*2000mm*2200mm
Koller Other Cold Room Technical Parameters:
Model |
Capacity (tons/24hours) |
Compressor Power (HP) |
Refrigerant |
Temperature (cent degree) |
Overall Dimension (L*W*H) (mm) |
VCR10 |
3 |
2.5 |
R404a |
-5°C- -20°C |
2500*2000*2200 |
VCR20 |
6 |
3 |
R404a |
-5°C- -20°C |
3000*3000*2200 |
VCR30 |
9 |
4 |
R404a |
-5°C- -20°C |
4000*3000*2500 |
VCR40 |
12 |
6 |
R404a |
-5°C- -20°C |
5300*3000*2500 |
VCR50 |
15 |
8 |
R404a |
-5°C- -20°C |
6800*3000*2500 |
VCR60 |
18 |
9 |
R404a |
-5°C- -20°C |
7000*3500*2500 |
VCR100 |
30 |
10 |
R404a |
-5°C- -20°C |
10000*3500*3000 |
VCR120 |
36 |
15 |
R404a |
-5°C- -20°C |
11500*3500*3000 |
VCR150 |
45 |
15 |
R404a |
-5°C- -20°C |
14300*3500*3000 |
VCR200 |
60 |
20 |
R404a |
-5°C- -20°C |
17000*4000*3000 |
Delivery Time (VCR10): 15 working days after deposit
Installation: Manual books and CDs are provided to instruct the installation step by step in every detail.
Pictures:
Compressor unit
Air cooler
