AISI 4130 API Sucker rod used for oil extraction with competitive price
- 99999 Set / Sets per Month
- China main port
- T/T
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Henan, China | Brand Name: | Puyang Zhongshi | Model Number: | ZS-SR0210 |
Theory: | Jet Pump | Structure: | Other, Contact | Usage: | Oil |
Power: | Other | Standard or Nonstandard: | Standard | Fuel: | Diesel |
Pressure: | High Pressure | Application: | Other, contact |
Product Description
Sucker Rod-API grade
1.Grade C sucker rod: It features moderate strength and good toughness and can be used in sour media environment, it is not susceptible to the sulfide stress cracking.
2.Grade D sucker rod: It is made of quality alloy steel and heat treated, it features high tensile and yield strength, good toughness, it is applicable to non-corrosion or light corrosion environment.
3.Grade V sucker rod: It features good resistance to corrosion, H2S, CO2 and NaCl media, and superior tensile strength. It is newly developed product and applicable to deep well pumping by small pump, forced production by large pump and production of thickened oil.
4.Grade H sucker rod: It is the high strength sucker rod. The structure and the size of Grade H sucker rod are same as those of Grade D sucker rod, but the strength reaches 966-1,136Mpa(140,000-164,720psi) and it is applicable to deep wells and large displacement well.
API Sucker Rod for oil equipment
Puyang Zhongshi Group is a specialized producer which produces the petroleum machinery such as oil tube, drilling collar, drill pipe and sucker rod etc.
The company had rich technical force with more than 30 specialties technician in the existing over 300 staff.The company certified ISO9001 Quality System Assessment and API Certificate, the number of API Certificate of our company are 11B-0081 for sucker rod and 7-1-0552 for drill collar .Its product and produce ability is:
1.sucker rod 10,000,000/every year
2.drilling collar 10,000 Pcs / every year
3.drill pipe 20,000 tons/ every year
The company would like to accept the special orders and to develop new products according to customer's requests. Under the policy friendship, equality and mutual benefit ,welcome to cooperate with all customers over the world.
Type | 25-150TH | 25-125TH | 25-175TH | 25-225TH |
CYB38TH | CYB32TH | CYB44TH | CYB57TH | |
Nominal Diameter | 38.1(1 1/2)/38 | 31.8(1 1/4)/32 | 44.5(1 3/4)/44 | 57.2(2 1/4)/56 |
Plunger length | 1200 | |||
Pump barrel length | 3300-6600 | |||
Thread for connection with top tubing | 2 7/8NU | 2 7/8NU | 2 7/8NU | 2 7/8NU |
B Thread B for connection with bottom oil pipe | 2 7/8NU | 2 7/8NU | 2 7/8NU | 2 7/8NU |
Thread for connection with oil rod | 3/4 in | 3/4 in | 3/4 in | 3/4 in |
Pump constant | 1.642(10.33) | 1.14(7.17) | 2.188(13.76) | 3.546(22.30) |
Max. outside diameter | 89.5 |
Anti-sand Sucker rod pump
Type | 25-150TH | 25-125TH | 25-175TH | 25-225TH | |
CYB38TH | CYB32TH | CYB44TH | CYB57TH | ||
Nominal diameter | 38.1(1 1/2)/38 | 31.8(1 1/4)/32 | 44.5(1 3/4)/44 | 57.2(2 1/4)/56 | |
Plunger length | 3000-6600 | ||||
Pump barrel length | 1200 | ||||
Thread for connection with top oil pipe | 2 7/8NU | 2 7/8NU | 2 7/8NU | 2 7/8NU | |
Thread for connection with bottom oil pipe | 2 7/8NU | 2 7/8NU | 2 7/8NU | 2 7/8NU | |
Thread for connection with oil rod | 3/4 in | 3/4 in | 3/4 in | 3/4 in | |
Pump constant | 1.642(10.33) | 1.14(7.17) | 2.188(13.76) | 3.546(22.30) | |
Max. outside diameter | 106 |
Bridge type Sucker rod pump
Type | 25-150TH | 25-125TH | 25-175TH |
CYB38TH | CYB32TH | CYB44TH | |
Nominal diameter | 38.1(1 1/2)/38 | 31.8(1 1/4)/32 | 44.5(1 3/4)/44 |
Plunger length | 1200 | ||
Pump barrel length | 3300-6600 | ||
Thread for connection with top tubing | 2 7/8NU | 2 7/8NU | 2 7/8NU |
Thread for connection with bottom oil pipe | 2 7/8NU | 2 7/8NU | 2 7/8NU |
Tread for connection with oil rod | 3/4 in | 3/4 in | 3/4 in |
Pump constant | 1.642(10.33) | 1.14(7.17) | 2.188(13.76) |
Max.outsidediameter | 88.9(3.5) | ||
Max. depth for lower pump | 2800(9190) | 3000 | 2500(8200) |
Anti-grain deposition sucker rod pump
Type | 25-150TH | 25-125TH | 25-175TH | 25-225TH |
CYB38TH | CYB32TH | CYB44TH | CYB57TH | |
Nominal diameter | 38.1(1 1/2)/38 | 31.8(1 1/4)/32 | 44.5(1 3/4)/44 | 57.2(2 1/4)/56 |
Plunger length | 1200 | |||
Pump barrel length | 3300-6600 | |||
Thread for connection top oil pipe | 2 7/8NU | 2 7/8NU | 2 7/8NU | 2 7/8NU |
Thread for connection with bottom oil pipe | 2 7/8NU | 2 7/8NU | 2 7/8NU | 2 7/8NU |
Thread for connection with oil rod | 3/4 in | 3/4 in | 3/4 in | 3/4 in |
Pump constant | 1.642(10.33) | 1.14(7.17) | 2.188(13.76) | 3.546(22.30) |
Max. outside diameter | 106 | |||
Requirement for sealing grade | 30-35 | |||
Max. permissible draw load | 500 | |||
Max. load for bearing hollow pin of drip | 1.0 | |||
Fracture success rate for hollow pin of drip | 100% | |||
Max. grain diameter of deposition in the cavity | 20 |
Sucker rod Certification
Sucker Rod Picturers
