B Serise Walking Beam Pumping Unit for Oil Production

B Serise Walking Beam Pumping Unit for Oil Production thumbnail-1
B Serise Walking Beam Pumping Unit for Oil Production photo-1
US$ 4,200 - 5,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
30 m³ per day
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Puyang Zhongshi Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Production Capacity 30 m³ per day
Place of Origin Henan, China
Brand Name ZS
Model Number B25D-67-36
Voltage 220v/380v
Power(W) 5.5kv
Dimension(L*W*H) 190x45x121
Weight 6900 lbs
Features B25D-67-36
Certification API 11E
Warranty 2 years
After-sales Service Provided Overseas third-party support available

Specifications

1, confirm to API 11E standard
2, Simple structure, Reliable, durable,
3, Size:B25D-67-36





Brief Introduction of the B-serise walking beam pumping unit



In order to adapt to the development of petroleum industry, our company developed an pumping unit of beam-balanced serial in combination with the factual situation of our country's oil field, aiming at the development direction of pumping units of deep pumping, long stroke and energy-saving, which are needed by such oil fields as not being able to perform flowing based on their oil layer energy.


Technical Performances

1)Walking Beam Balance


2)25 Retarder Rating Torque 25000lbs.in


3)Retarder Adopting Double-circular-arc Helical Gearing System



4)6700lbs Rating Polished Rod Load



5) Stroke 36in









Item Pumping
unit type		 Lifting
Capacity(lbs)		 Stroke
Length(in)		 Rated
torque(in.lbs)
1 C-912D-470-240 47,000 240 211 181  912,000
2 C-912D-427-216 42,700 216 185 155 912,000
3 C-912D-427-192 42,700 192 165 138 912,000
4 C-912D-305-192 30,500 192 165 138 912,000
5 C-912D-365-168 36,500 168 144 121 912,000
6 C-912D-305-168 30,500 168 144 121 912,000
7 C-912D-427-144 42,700 144 123 102 912,000
8 C-640D-305-192 30,500 192 165 138 640,000
9 C-640D-305-168 30,500 168 144 121 640,000
10 C-640D-365-144 36,500 144 123 102 640,000
11 C-640D-305-144 30,500 144 123 102 640,000
12 C-640D-256-144 25,600 144 123 102 640,000
13 C-640D-305-120 30,500 120 102 84 640,000
14 C-456D-305-168 30,500 168 144 121 57,000
15 C-456D-305-144 30,500 144 123 102 40,000
16 C-456D-256-144 25,600 144 123 102 57,000
17 C-456D-365-120 36,500 120 102 84 40,000
18 C-456D-305-120 30,500 120 102 84 25,000
19 C-456D-256-120 25,600 120 102 84 25,000
20 C-320D-256-144 25,600 144 123 102 320,000
21 C-320D-256-120 25,600 120 102 84 320,000
22 C-320D-213-120 21,300 120 102 84 320,000
23 C-320D-305-100 30,500 100 85 70 320,000
24 C-320D-256-100 25,600 100 85 70 320,000
25 C-320D-213-86 21,300 86 71 56 320,000
26 C-228D-213-120 21,300 120 102 84 228,000
27 C-228D-173-100 17,300 100 86 72 228,000
28 C-228D-246-86 24,600 86 71 56 228,000
29 C-228D-213-86 21,300 86 71 56 228,000
30 C-228D-200-74 20,000 74 64 54 228,000
31 C-228D-173-74 17,300 74 64 54 228,000
32 C-160D-173-86 17,300 86 74 62 160,000
33 C-160D-200-74 20,000 74 64 54 160,000
34 C-160D-173-74 17,300 74 64 54 160,000
35 C-160D-143-74 14,300 74 64 54 160,000
36 C-160D-173-64 17,300 64 54 44 160,000
37 C-114D-119-86 11,900 86 72 59 114,000
38 C-114D-143-74 14,300 74 62 51 114,000
39 C-114D-173-64 17,300 64 54 44 114,000
40 C-114D-143-64 14,300 64 52 40 114,000
41 C-114D-133-54 13,300 54 45 36 114,000
42 C-80D-119-64 11,900 64 53 42 80,000
43 C-80D-133-54 13,300 54 45 36 80,000
44 C-80D-119-54 11,900 54 45 36 80,000
45 C-80D-133-48 13,300 48 40 32 80,000
46 C-80D-109-48 10,900 48 37 25 80,000
47 C-57D-76-54 7,600 54 41 28 57,000
48 C-57D-109-48 10,900 48 37 25 57,000
49 C-57D-95-48 9,500 48 37 25 57,000
50 C-57D-89-42 8,900 42 33 23 57,000
51 C-57D-76-42 7,600 42 33 23 57,000
52 C-40D-76-48 7,600 48 37 27 40,000
53 C-40D-89-42 8,900 42 33 23 40,000
54 C-40D-76-42 7,600 42 33 23 40,000
55 C-40D-89-36 8,900 36 28 20 40,000
56 C-25D-67-36 6,700 36 28 20 25,000
57 C-25D-56-36 5,600 36 28 20 25,000
58 C-25D-53-30 5,300 30 20 25,000


 B serise walking beam pumping unit for oil Production





4, Loading on the container



B serise walking beam pumping unit for oil Production





5, Spare parts photos







B serise walking beam pumping unit for oil ProductionB serise walking beam pumping unit for oil ProductionB serise walking beam pumping unit for oil ProductionB serise walking beam pumping unit for oil Production
