Help CenterSubsurface Sucker Rod Pump
Related Products
Specifications
1. API spec. 11 AX standard2. More than ten years exporting experience
3. Type: rod pump, tubing pump
4. Anti-corrosion
1.Descriptions:
Comparing with conventional tubing pump,The API Tubing Pump has better performance in corrosion resistance & antifriction aspects.Plunger of it is nickel plated on alloy base,inside wall of barrel is plated hard cadmium,key parts,such as valve hood,valve ball,are made of materials with excellent mechanical performance and corrosion resistant property.Compared with conventional pump,the series of pump has a longer working life.
2.Specification:
1. Double or Single Chrome plated or nickle sprayed plunger
2. Pump bore: 125-375
3. Barrel length:8-30ft
4. Plunger length:2-7m
5.anti-corrosion and anti-friction
3.Technical performances:
1. The pump barrel machined by using the high quality special purpose blank, the internal surface has the chrome-plating or the nickel phosphorus compound plating superficial strengthening processing to achieve the good intensity, the rigidity, wear-resistance and anti-corrosion.
2. The valve ball and the valve seat made by using high-carbon chromium stainless or ceramics or tungsten carbide material to achieve longer life span.
3. The plunger surface uses the nickel base alloy powder to spurt welding to achieve good wear-resistance and anti-corrosion ability.
4. The pump efficiency is high, pump inspection cycle is longer.
5. Simple structure with easy installation and usage
4.Main specifications and parameters
|
Nominal diameter mm |
Length series of the plunger m |
Extension nipple length m |
Stroke range of the plunger m |
O.D. of the connecting oil pipe mm |
Diameter of the connecting pumping rod mm |
Pump constant m3/d |
Max. O.D. mm |
28 |
0.6 0.9 1.2 1.5 |
0.3 0.6 0.9 |
0.6-6.0 |
60.3,73.0 |
16 |
0.916 |
88.9 |
32 |
60.3,73.0 |
16 |
1.140 |
88.9 |
|||
38 |
60.3,73.0 |
16/19 |
1.642 |
88.9 |
|||
44 |
60.3,73.0 |
19 |
2.235 |
88.9 |
|||
57 |
73.0 |
19 |
3.694 |
88.9 |
|||
70 |
88.9 |
22 |
5.518 |
107 |
|||
83 |
101.6 |
22 |
7.707 |
114 |
|||
95 |
114.3 |
25 |
10.261 |
121 |
