Help CenterCentrifugal Sand Pump
Related Products
Specifications
centrifugal sand pump1.Easy to installation
2.Compact structure
3.Long service life and low price
4.Good quality
1. Descriptions
The pump is adopted advanced leakproof structure and the flow parts are choosed to use in Abrasion-proof material, light weight, easy to disassemble and install, long working life , pump efficiency is more than 74% .The pump is mainly used together with drilling fluid solid control equipments, as well as filling pump of drilling fluid .
2. Characteristics
Unique mechanical seals and packing seal, good sealing performance, high working efficiency
3. Technical parameter
Specification |
SB 150 |
Lift |
20-30 m |
Delivery capacity |
200-260 m3/h |
Power |
37-75 Kw |
Rotating speed |
1400 r / min |
Inlet and outlet size |
φ200×φ150 |
Weight |
800 kg |
Specification |
SB10×8-14 |
SB8×-14 |
SB8×6-11 |
SB6×5-11 |
SB4×3 |
Delivery capacity(m3/h) |
260~280 |
240~260 |
220~240 |
120~220 |
60 |
Lift(m) |
28~33 |
28~33 |
24~28 |
24~28 |
22~28 |
Efficiency |
65% |
65% |
65% |
65% |
65% |
Power (KW ) |
75 |
55/75 |
37/45 |
30/37/45 |
11/15 |
Rotating speed(rpm) |
1450/1750 |
1450/1750 |
1450/1750 |
1450/1750 |
1450/1750 |
Inlet Dia. |
10” |
8” |
8” |
6” |
4” |
Outlet Dia. |
8” |
6” |
6” |
5” |
3” |
Weight(kg) |
1150 |
1000/1150 |
920/1050 |
819/887/920 |
438/460 |
|
Dimensions (mm) L×W×H |
2020×675×950 |
1930×650×880 1200×675×950 |
1848×595×805 1875×595×805 |
2020×675×950 1820×585×805 1845×585×805 |
1545×500×710 1585×500×710 |
