Help Center3 1/2 Eue Tubing Coupling for the Seamless Pipe Fitting
Related Products
Description:
Tubing Coupling can be widely used in cold and hot water supply, heating supply, fire protection, medicinal gas, industrial petroleum pipeline system etc. It has already replaced welding fittings in most Europe countries, Asia countries, America, Australia and some other countries.Specification:
| Descriptions and size | Type of Therad | O.D*L (mm) |
Weight (kg) |
|
| Tubing Coupling |
1.050 | NUE | 33.35*80.96 | 0.23 |
| 1.050 | EUE | 42.16*82.55 | 0.38 | |
| 1.315 | NUE | 42.16*82.55 | 0.38 | |
| 1.315 | EUE | 48.26*88.90 | 0.57 | |
| 1.660 | NUE | 52.17*88.90 | 0.59 | |
| 1.660 | EUE | 58.88*95.25 | 0.68 | |
| 1.900 | NUE | 55.88*95.25 | 0.56 | |
| 1.900 | EUE | 63.50*98.42 | 0.84 | |
| 2-3/8" | NUE | 73.02*107.95 | 1.28 | |
| 2-3/8" | EUE | 77.80*132.82 | 1.55 | |
| 2-7/8" | NUE | 88.90*130.18 | 2.34 | |
| 2-7/8" | EUE | 93.17*133.35 | 2.40 | |
| 3-1/2" | NUE | 107.95*142.88 | 3.71 | |
| 3-1/2" | EUE | 114.30*146.05 | 4.10 | |
| 4" | NUE | 120.65*146.05 | 4.35 | |
| 4" | EUE | 127.00*152.40 | 4.82 | |
| 4-1/2" | NUE | 132.08*155.58 | 4.89 | |
| 4-1/2" | EUE | 141.30*158.75 | 6.05 | |
| Casing Coupling |
4-1/2" | STC | 127.00*158.75 | 5.23 |
| 4-1/2" | LTC | 127.00*177.80 | 4.15 | |
| 4-1/2" | BTC | 127.00*225.42 | 4.55 | |
| 5" | STC | 141.30*165.10 | 4.66 | |
| 5" | LTC | 141.30*196.85 | 5.75 | |
| 5" | BTC | 141.30*231.78 | 5.85 | |
| 5-1/2" | STC | 153.67*171.45 | 5.23 | |
| 5-1/2" | LTC | 153.67*203.20 | 6.42 | |
| 5-1/2" | BTC | 153.67*234.95 | 6.36 | |
| 6-5/8" | STC | 187.71*184.15 | 9.12 | |
| 6-5/8" | LTC | 187.71*222.25 | 11.34 | |
| 6-5/8" | BTC | 187.71*244.48 | 11.01 | |
| 7" | STC | 194.46*184.15 | 8.39 | |
| 7" | LTC | 194.46*228.60 | 10.83 | |
| 7" | BTC | 194.46*254.00 | 10.54 | |
| 7-5/8" | STC | 215.90*190.50 | 12.30 | |
| 7-5/8" | LTC | 215.90*234.95 | 15.63 | |
| 7-5/8" | BTC | 215.90*263.52 | 15.82 | |
| 8-5/8" | STC | 244.48*196.85 | 16.23 | |
| 8-5/8" | LTC | 244.48*254.00 | 21.67 | |
| 8-5/8" | BTC | 244.48*269.88 | 20.86 | |
| 9-5/8" | STC | 269.88*196.85 | 18.03 | |
| 9-5/8" | LTC | 269.88*266.70 | 25.45 | |
| 9-5/8" | BTC | 269.88*269.88 | 23.16 | |
| 10-3/4" | STC | 298.45*203.20 | 20.78 | |
| 10-3/4" | BTC | 298.45*269.88 | 25.74 | |
| 11-3/4' | STC | 323.85*203.20 | 22.64 | |
| 11-3/4' | BTC | 323.85*269.88 | 28.03 | |
| 13-3/8" | STC | 365.12*203.20 | 25.66 | |
| 13-3/8" | BTC | 365.12*269.88 | 31.77 | |
| 16" | STC | 431.80*228.6 | 34.91 | |
| 16" | BTC | 431.80*269.88 | 40.28 | |
| 18-5/8" | STC | 508.00*228.60 | 51.01 | |
| 18-5/8" | BTC | 508.00*269.88 | 62.68 | |
| 20" | STC | 533.40*228.6 | 43.42 | |
| 20" | LTC | 533.4*292.10 | 57.04 | |
| 20" | BTC | 533.40*269.88 | 50.10 | |
Standard export packing or as customers' requirements
Other products supply:
1. pumping unit
2. Tubing pump/sucker rod pump and accessories
3. Float collar and float shoe
4. Casing centralizer
5. Cementing plug
6. Cementing head
7. Stage Collar
8. Casing/ Tubing coupling
9. Drill pipe
10. Sucker rod
11. Thread protector
12. Air blaster
The predecessor of Henan Puyang Zhongshi Group Co. Ltd, was the 5th Machine Repairing Factory of Puyang Zhongyuan Oil field, Sinopec Corp. In 1997, after being restructured according to the modern corporate system, the factory was named Puyang Zhongshi Group Co.,Ltd.
With registered capital of 60,840,000 yuan, Puyang Zhongshi Group is composed of 9 subsidiaries, including 8 manufacturers and 1 trade company. Zhongshi Group covers an area of 200,000 sq.m, including workshop area of 50,000 sq.m. Various kinds of production equipment values 38,600,000 yuan. It has a strong mechanical processing capability.
Our leading products are pumping unit, tubing pump & sucker rod pump, cementing accessories, down-hole tools, wellhead (X-mas tree), drilling solid control series, pressure vessel ,camping house, air cannon, belt feeder and so on. They are mainly supplied to Central Asia, Southeast Asia, Africa and Middle East and many other countries.
Zhongshi Group has been the Tier One internet service provider of Sinopec. We passed ISO9001 quality management system certification and got approved to use API monograms on its oil machineries. So far, we have attained API 5CT, API 10D, API 11AX, API 11E and more are applying for.
With strong technical backup, reliable product quality, advanced marketing regime and good service system, this company wins popularity and recognition of vast consumers home and abroad.
We would like to faithfully cooperate with friends from all circles with classic products and service to achieve common development.
