6x24 500m Optical Laser Meter with Angle Measurement LRAD1

Specifications

1. Monocular Range Finder
2: Angle measuring
3: LCD display
4: Magnification:6x
5: Objective:24mm

Optical Laser Meter with Angle Measurement and Speed Measurement

Specifications:

Measuring Range of distance:	6—400~1000m
Laster type	905nm
Objective diameter:	24mm
Eyepiece diameter:	16mm
Magnification:	6x
Field of view:	7 degree
Exit pupil diameter:	3.9mm
Diopter adjust ranger:	+/- 4
Operating temperatures:	-20-50 degree Celsius
Range measure accuracy:	+/-1M(Y)+/-0.2%
Function 1	Angle measuring(±60°) ±1°
Function 2	Height measuring(1-300m) ±1m
Battery:	CR2/3V
Unit weight:	185g
Unit dimension:	104x72x41mm
Packing	60pcs/ctn
N.W.	15KG
G.W.	16KG
Carton dimensions:	36cm x 48cm x 38cm

Packing Details:

1) QTY./CTN: 60pcs
2) G.W: 16kgs
3) N.W.:15kgs

Application:
Whether your'e golfing, hunting or conducting forestry survey, knowing the right distance is essential. Known industry-wide for superior optical technologies and cutting-edge design capabilities, Srate takes pride in delivering innovative, high-quality products. The Laser Rangefinder lineup extends from a high-spec model with angle measurement functions to models exclusively designed for golfing and hunting, each perfectly suited to its particular purpose.



What we supply:

1) OEM is available.2) One color logo printing is free! ~

3) The measuring distance can be made according to customer' needs. (6m-1300m)

4) The function can be made according to customer' needs . ( Distance measurement, speed measurement ,angle measurement height measurement and golf pin seeker functions)

5) Customized clours
