Specifications
1:Rangefinder constant measurement2:Speed detecting
3:Innovative lens coating
4:Water proof
Scanning Laser Rangefinder with Meter Measueing and Angle Measuring
Specifications:
| Measuring Range of distance: | 6—500m |
| Laster type | 905nm |
| Objective diameter: | 24mm |
| Eyepiece diameter: | 16mm |
| Magnification: | 6x |
| Field of view: | 7 degree |
| Exit pupil diameter: | 3.9mm |
| Diopter adjust ranger: | +/- 4 |
| Operating temperatures: | -20-50 degree Celsius |
| Range measure accuracy: | +/-1M(Y)+/-0.2% |
| Function 1 | Distance measuring |
| Function 2 | Speed measuring |
| Battery: | CR2/3V |
| Unit weight: | 185g |
| Unit dimension: | 104x72x41mm |
| Packing | 60pcs/ctn |
| N.W. | 15KG |
| G.W. | 16KG |
| Carton dimensions: | 36cm x 48cm x 38cm |
What we supply:
1) OEM is available.
2) One color logo printing is free! ~
3) The measuring distance can be made according to customer' needs. (6m-1300m)
4) The function can be made according to customer' needs . ( Distance measurement, speed measurement ,angle measurement height measurement and golf pin seeker functions)
5) Customized clours
Application:
Laser rangefinder monocular can widely used in all kinds of engineering surveying and mapping, the power patrol, forestry survey and design, construction, network planning survey and design, communication maintenance, etc., it can improve the efficiency of outdoor work, it also is the good helper of measuring object distance.
This model can also be made with angle measuring and height measuring functions
