Help CenterZP-17E Rotary Pill Press
Related Products
-
ZP-265 High Speed Rotary Tablet PressNegotiableMOQ: 1 Set -
JDG Series Vacuum Lyophilizer for FoodNegotiableMOQ: 1 Set
-
JDG Series Vacuum LyophilizerNegotiableMOQ: 1 Set
-
ZPT-21 Rotary Tablet Press Good Quality Pill PressNegotiableMOQ: 1 Set
-
JDG Series Vacuum Freeze Dryer for FoodNegotiableMOQ: 1 Set
We can supply a complete set according to the users' requirements.
Specifications
GMP Standard
PLC Control
Pre-pressure and Over-load Protection System
Highly Cost Effective
Easy for Operation
Application:
This machine is suitable for pressing various kinds of granular materials into round tablet or different geometrical shape tablets, specially for small-scale batch production.
Feature:
1. Made of stainless steel, the housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirement.
2. Adopt transparent windows, tableting state can be observed clearly. The windows can be opened, cleaning and maintenance is easy.
3. All the drive devices are located inside the machine so keep the machine clean.
4. The machine can stop automatically in case of overpressure.
5. With pre-pressure roller, extending the pressing time and making good quality tablets.
6. Force feeder is optional.
Technical Specifications:
Model |
ZP17E |
|
Number of Stations |
17 |
|
Max Main Pressure (KN) |
50 |
|
Max Pre-pressure (KN) |
10 |
|
Max Tablet Diameter |
round tablet |
20 |
irregular tablet |
22 |
|
Max Filling Depth (mm) |
15 |
|
Max Tablet Thickness (mm) |
6 |
|
Max Turret Speed (r/min) |
40 |
|
Max Production Capacity (pcs/h) |
40800 |
|
Motor Power (kw) |
2.2 |
|
Overall Size (mm) |
950×770×1740 |
|
Machine Weight (kg) |
900 |
|
