Specifications
It is applicable for water and air spray washing.Hot air laminar dryand sterilize, multiple needle filling and sealing.
We can supply a complete set according to the users' requirments.
Specification
It is applicable for water and air spray washing.Hot air laminar dry
and sterilize, multiple needle filling and sealing.
AKGFS8 AMPOULE FILLING-SEALING MACHINE is applicable for water and air spray washing alternately the Btype easily broken retort ampoule, hot air laminar dry and sterilize, multiple needle filling and sealing.
The whole machine is under PLC control, it can be linked controlled, and it can be operated with single machine. The working state of each position can be automatically supervised, and it is displayed by light pole, or by man-machine interface.
In the clean room, detector may be mounted for site supervision, and automation control level is high. This machine has PC automatic checking function, once the machine is failed, it can shut down the machine immediately and display the failure position and display trouble shooting for easy repair.
The vertical ultrasonic wave washing machine is designed with over-load protection device, once the main shaft is over-load, it will shut down the machine immediately.
On the washing control cabinet, there are lights feedback the working states of the filling machine and visual talking, or man-machine interface display and control.
The operator can know the working state in the cleaning room at any time. The sterilization dryer uses surface cooler technology, it completely realizes no-suction wind and zero discharge. The table of the filling machine is stop type for easy washing, it has optional peristaltic pump, glass pump and ceramic piston pump for customer to choose.
The application of the servo motor driving, PLC, frequency converting speed
regulation and the technology coordinating each functional mold with servo motor makes the control system reach the world advanced level.
The control operation can also provide visual talking device according to customer requirement. He global qualified rate can reach to above 99%.
The ampoule filling and sealing machine (hereinafter called FS machine) is used for the filling and sealing of 1ml, 2ml, 5ml, 10ml, 20ml ampoules. It can charge nitrogen, fill and seal to 8 ampoules at one time.
This machine has functions of stop filling on lack of bottle, high position stop machine, and etc. Above the machine, there is an air purifying device reaching class 100 cleanness. The main machine and inlet bottle conveying net belt are all stepless speed change. This machine can be singly used, and can also be used with tunnel sterilization dryer (hereinafter called dryer), ampoule ultrasonic wave cleaner (hereinafter called cleaner). This machine has merits of high production, good quality, stable and reliable running and convenient operation. All materials conform to GMP requirements, only expend several hours to change small amount of parts, so that the
machine can fill and seal ampoules of other sizes.
Model number AKGFS8
Applicable specification: 1ml,2 ml,5ml,10ml,20ml
Capacity: (ampoule/hour)
1ml,2 ml----------- 21000
5ml -------------------16000
10ml -----------------11000
20ml -----------------6000
Filling precision Conforming to <Pharmacopoeia of the Peoples Republic of China>
Filling pump precision ≤±2%
Product qualified rate ≥99%
Distilled water 0.25Mpa 50 0.6m3/h
Compressed air 0.25Mpa ≈60 m3/h
Power 6024KW
Vacuum Suction rate 17 m3/h
Extreme vacuum 150mbar
Outline dimension 8920x2345x2350(mm)
Weight ~6400kg
