FD-1 Laboratory Freeze Dryer

FD-1 Laboratory Freeze Dryer thumbnail-1
FD-1 Laboratory Freeze Dryer photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Freeze Drying Equipment
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Pharmaceutical Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Freeze Drying Equipment
Place of Origin Shanghai, China
Brand Name SPM
Model Number FD
Voltage 220V
Power(W) 800W
Dimension(L*W*H) 405mm 630mm 800mm
Weight 20kg
Certification ISO
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas



Features:

1. Vertical design, compact structure, small took up the space;

2. Beautiful shape, the human body engineering design, easy operation;

3. The original imported enclosed compressor, efficient and reliable, low noise;

4. Double compressor cascade refrigeration, mature technology, low temperature;

5. Cryotrapping openings, samples pre-frozen function;

6. Stainless steel cryotrapping, cold inside the well pipe no disk, bright and clean and corrosion resistance;

7. Patent design diversion tube, improve cryotrapping effective area, rapid freeze-drying;

8. The original imported filling the air valve, charged dry nitrogen or inert gases;

9. Transparent organic glass bell prover dry room, safe and direct;

10. International standard vacuum connection, convenient remove and installation, reliable  seal performance;

11. Digital display temperature and vacuum;

12. Optional sample temperature display.

 FD-1 Laboratory Freeze Dryer

Technical parameters:

Model                          FD-1(ordinary)

Condensation temperature        <-55°C

True empty degree               <15Pa (light)

Lyophilized area                 0.12m2 5L

Capture water capacity           3Kg/24h

Sample product plate            Φ200mm×4 layers

Power supply requirements       220V 50Hz 800W

Host size                       405mm×630mm×(320+480)mm
