Help CenterS-200 ABS Capsule Filling Device
Related Products
Specifications
1. ABS engineering plastics2. Easy to operation and cleaning
3. Small size
4. Cheap cost
Product Features:
Plate the latest version of the S -200 precision capsule (capsule, capsule filling filling plate plate) by our factory recently made precision
mould injection molding, machining center after the test, was welcomed by the user's wide acclaim and
dealers. The latest version of the S-200 precision capsule plate arranged plate, hats, middle plate,
plate, pressure powder and powder panels, made of organic glass materials not only include all the
advantages, and has more advantages than organic glass:
1: non-toxic environmentally friendly materials, non-toxic odorless (plexiglass more or less pungent
odor).
2: The smooth rounded edges and holes capsules, feel comfortable (plexiglass corners have saw
marks, white side, there will be a feeling of assassination feel and unsightly).
3: The board as a whole a cap made of sturdy unbreakable (plexiglass panel consists of a cap capsule
hole drilled plexiglass late plus a thin plexiglass plate, in the middle of the length of the capsule and
plexiglass thickness pad piece paving, so is likely to result in the use of thin plexiglass plate cracked
damaged).
4: plates with holes that a thickness of 6.5MM, more strong and difficult to deform (plexiglass only 5MM).
5: Arrange disc capsules arranged holes radian fit, deep enough, arrange capsules capsules very
easy to get into the extra hole arranged in the capsule is very easy to pour out (plexiglass extra hole in
the capsule are arranged relatively easy to pour out).
6: The mold injection molding, the overall accuracy is good (plexiglass is positioned before the first
punch is made with a drill, tools and operations due to the reasons for bias).
7: Pressure plate with powder injection molding mold, ejector plate spacing and pitch capsules to complete one, with the same material handle, easy to use. (Plexiglass plate is pressed powder after the plug hole in the plexiglass plate made of aluminum rod, aluminum would shake, when the pressure will damage the capsules are not careful,
the handle stamped by the iron plating, feel bad when used the course of time and will rust).
8: The product is durable without deformation (plexiglass easy to turn yellow, deformed, poorly
preserved can not be reused).
Products:
1. Guide plate arranged 1pc (four sides of the border),
2. Cap plate 1pc,
3. Plates 1pc,
4. Intermediate plate 1pc (single layer),
5. Spatulas plate 1pc (for the powder distributed uniformly inside the capsule body),
6. Pressed powder board block 1pc(for compacting powder capsules, to increase the filling amount of the powder), with handle.
Model: 0 # capsule
Specifications: S-200 (a fill 200 capsules per time)
Uses: 0 # capsule powder filling (filling)
Material: ABS
Powder filling rate: 100%
Lock pass rate: ≥ 100%
Hole accuracy : R0.05mm
Filling precision: W ± 5%
Capacity :2000-4000 / hour
Length and width: 30 * 17cm
Weight: 1.8kg
Packed weight: 2.5kg
