HF-60AB
Main specifications:
Maximum input power: 60KW
Oscillating frequency: 30-80KHz
Heating current: 20-130A
Maximum input current: 110A
Input voltage: 380VAC 3phases, 50 or 60Hz
Duty cycle: 100%
Cooling water: ≥0.2Mpa 10L/min
Auto heating time: 1-99seconds
Auto retaining time: 1-99seconds
Auto cooling time: 1-99seconds
Weight and dimension:
Model |
Net weight(KG) |
Size: L x W x H (mm) |
Packing weight |
Pacing size: L x W x H (mm) |
HF-70AB generator |
79KG |
650x310x590mm |
188KG |
920x850x990mm |
HF-70AB transformer |
70KG |
550x270x400mm |
Main models and specifications:
Model |
Maximum input power |
Oscillating frequency |
Max input current |
Input voltage |
Duty cycle |
HF-15A/AB |
7KW |
30-100KHz |
32A |
Single phase 220V 50Hz |
80% |
HF-25A/AB |
15KW |
30-80KHz |
23A |
3phase 380V 50Hz |
100 |
HF-25ABD |
25KW |
30-80KHz |
38A |
3phase 380V 50Hz |
100% |
HF-35AB |
35KW |
30-80KHz |
55A |
3phase 380V 50Hz |
100% |
HF-45AB |
45KW |
30-80KHz |
68A |
3phase 380V 50Hz |
100% |
HF-70AB |
70KW |
30-80KHz |
105A |
3phase 380V 50Hz |
100% |
