SHS1062,siglent Oscilloscope,multimeter Oscilloscope,handheld Oscilloscope

SHS1062,siglent Oscilloscope,multimeter Oscilloscope,handheld Oscilloscope thumbnail-1
SHS1062,siglent Oscilloscope,multimeter Oscilloscope,handheld Oscilloscope photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Siglent
Model Number:
SHS1062
Contact Supplier Request Quote Chat Now
Xiamen Wellzion Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Siglent
Model Number SHS1062

SHS1000 Series develop with patent Isolated Channel technology to provide isolation from ground and isolation between Channels

SHS1062,siglent oscilloscope,multimeter oscilloscope,handheld oscilloscope

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SHS1062,siglent oscilloscope,multimeter oscilloscope,handheld oscilloscope

Oscilloscope Specification
Model SHS1062 SHS1102
bandwidth 60MHz 100MHz
Rise time ≤5.8ns ≤3.5ns
Real Time Sample Rate 1GS/s
Equivalent Sample Rate 50GS/s
Vertical Sensitivity 5mV~100V/div
Time Base Scale 5ns~50s/div 2.5ns~50s/div
Scan:100ms~50s/div
 Memory  Depth 2Mpts
Triggering Edge,Pulse,Video,Alternative,Slope
Vertical Resolution 8 Bit
Hardware Counter 6 Digital Triggering Frequency Counter
Port USB Device,USB Host
Math Operation +,-,*,/,FFT
Display Color TFT-LCD,320×234 Display
Multimeter Specification
Maximum Resolution 6000
Ltem Range Accuracy
DC Voltage  60mV - 1000V  ±1%±5digit
AC Voltage  60mV –750V  ±1%±5digit
DC Current  60mV -10A ±1%±5digit
AC Current 60mV -10A    ±1%±5digit
Capacitance  40.00nF    ±3%±10digit
 400.0nF-400.0uF    ±4%±5digit
Resistance  600Ω - 60MΩ  ±1%±5digit
On off Test <50Ω
Diode 0V~2.0V
Trend Port 1.6M Points
Recoder 7M Points
Measuring Mode Manual/Auto
Isolation Level
Max input Voltage
Input by input port directly 300V CAT II
Input by 10:1 probe 1000V CAT III,600V CATIII
The Max input voltage of Multimeter DC 1000V,AC 750V
Max float voltage
The float voltage between Oscilloscope BNC and ground 1000V CAT III,600V CATIII
The float voltage between each channel 1000V CAT III,600V CATIII
The float voltage between Multimeter and ground 1000V CAT III,300V CATIII
Security :Isolated Handled Oscilloscope should be designed according to the standard of level II and pollution degree level lI ,which apply to measure 1000V;or according to the standard of level III and pollution degree level lI,which apply to measure 600V
General Feature
Display Color TFT-LCD,320×240 Display
Power Supply With battery or apply DC adapter to get power from outside
Power Source Built-in rechargeable lithium battery:7.4V 4400mAh,Battery Last3.5 hours;
With DC adapter:100-240V 50/60Hz output 8.5V 2.8A output.
Weight 1.5Kg
Size 259×163×53mm
Accessory Two Passive probes, Power cable, DC adapter, Multimeter Pen

-----------------------------------------------------------------------------------------------------------------------------------------

SHS1062,siglent oscilloscope,multimeter oscilloscope,handheld oscilloscope

------------------------------------------------------------------------------------------------------------------------------------------

SHS1062,siglent oscilloscope,multimeter oscilloscope,handheld oscilloscope

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SHS1062,siglent oscilloscope,multimeter oscilloscope,handheld oscilloscope



Compare with Fluke190 Series

Specification SHS1000 Fluke 190 (2-Channel)
Bandwidth SHS1062: 60MHz Fluke192: 60MHz
SHS1102: 100MHz Fluke196: 100MHz
  Fluke199: 200MHz
Real-time sample rate 1 GS/s Fluke192: 500MS/s
Fluke196: 1GS/s
Fluke199: 2.5GS/s
Depth Memory 2MKpts <20kpts
Number of Channels 2 2
Independently floating isolated inputs Up to 1000 V CAT II/600 V CAT III between inputs, references and ground Up to 1000 V CAT II/600 V CAT III between inputs, references and ground
Timebase range SHS1062:5 ns - 50s/div Fluke192:10 ns - 2 min/div
SHS1102:2.5 ns - 50s/div Fluke196:5 ns - 2 min/div
  Fluke199:5 ns - 2 min/div
Input sensitivity 5 mV-100 V/div 5 mV-100 V/div
Trigger types edge,pulse,video,alternative,slope,Single Shot,Normal,Auto Automatic,Edge,External,Video,Pulse Width
Maximum record length Trend Plot:1.4M points
Recoder:6M points		 Trend Plot:13500 points
Record :27500 points
Memory Screen + Setup: 30
Recording: 2		 Screen + Setup: 20
Recording: 2
Display 5.7" Color TFT-LCD, 320×234 144 mm,320 x 240 Display
Waveform Compare Waveform reference with automatic Pass/Fail testing
Oscilloscope Trend Plot 800K 13500
Meter Mode
Max.Resolution 6000 5000
DMM Testing Modes Voltage, Current, Resistance, Capacitance,Diode & Continuity

Voltage,Resistance,Diode&Continuity,

Temperature
Max. Input Voltage AC:750V DC:1000 AC:1100V DC:1100
Max. Input Current AC:10A DC:10A Not supported
Resistance 600Ω-60MΩ 500Ω-30MΩ
Multimeter Trend Plot 1.6M points 27500
General Feature
Operating Altitude 3,000 m 3,000 m
Size 259.5 x 163.2 x 53.3 mm 256 x 169 x 64mm
Weight 1.5Kg 1.95 kg
Warranty 3-years on main instrument, 1-year on accessories
Li-Ion Battery 4500mAh,Battery Last3 hours 2400mAh,Battery Last4 hours
