Product Details
Brand Name: | OEM | Model Number: | TC722 |
Product Description
TC722,10G Gigabit Modular Ethernet Transport Tester
The TC722 is an all-in-one Transport Layer Tester released to support full protocol testing at rates up to 10Gbps.The TC722 provides expert analysis for next-generation high-speed Metro and Carrier Transport networks, validating performance and connectivity while cutting OPEX and CAPEX.It is an efficient testing tool for service providers to satisfy client service level agreements (SLAs).
The TC722 is ideal for any transport testing task. It is fully equipped for Ethernet performance assessment; Metro Ethernet / SONET/SDH, and Mobile Backhaul installation, activation, or maintenance; point-to-point Ethernet access deployment; online troubleshooting for real-time information flow and more.The tester supports multiple communication protocols to meet different testing requirements, including SyncE, IEEE 1588v2, E1/T1, SDH / SONET, and OTN.
- Network engineering site installation and activation test
- Service providers can evaluate data transmission network performance with complete end-to-end testing
- Local, Metro Ethernet construction, deployment and maintenance
- PTN/IPRAN network configuring and performance testing
- Communication Teaching and Research
- 7 inch TFT LCD touch screen
- Two 10GbE SFP+ ports, two 10/100/1000Base-T RJ45 ports
- Dual ports can test different setups independently
- Complies with RFC 2544 standard Throughput, Latency, Frame Loss and Back-to-Back benchmarking
- Complies with ITU-T Y.1564 Service Activation Methodology (SAM) up to 10 independent streams
- Supports Terminal and Transparent Transmission test models
- Supports OTN, OTN-1, OTN-1e, OTN-1f, OTN-2, OTN-2e, OTN-2f test
- Supports external synchronize clock input, SyncE and IEEE 1588v2
- Supports optical power measurement
Ethernet Measurement | |
RFC 2544 | Throughput, Delay, Delay Jitter, Frame loss, back to back |
Y.1564 | Service configuration testing, service performance testing, supports up to 10 different traffic |
BERT | Support L1-L4 BERT support, insert error, frame error, PRBS, user-defined patterns |
Traffic generation and monitor | Supports up to 10 different traffic QoS and BER testing |
Smart Loopback | L1-L4 |
Pass Through mode | Support |
Delay measurement | Round Trip Delay |
SyncE | Support BITS, Ethernet line clock, internal high-stability clock source |
VLAN | 3 layers VLAN (QinQ) |
MPLS | 3 layers MPLS |
IEEE1588v2 | Support |
OAM | IEEE802.3 OAM |
IPv6 | Support |
SDH Measurement | |
BERT | Insert errors, detect error |
RTD | Get network round trip delay and network QoS information |
APS | Automatic protection switching time and service interruption time test |
Insert/discard specified tributary test | Insert the specified tributary, discard the specified tributary. |
OTN Measurement | |
BERT | Insert errors, detect error |
RTD | Get network round trip delay and network QoS information |
APS | Automatic protection switching time and service interruption time test |
Function | |
Online help | Support |
Recovery factory settings | Support |
Name file in Chinese | Support |
Screen shot function | Support |
Touch-screen soft keyboard input | Support |
Browser | Support |
Timing shutdown and sleep | Support |
File format | PDF, CSV |
Configure file | Save personalized configure file, can import and export |
Language | English, Chinese |
General | |
Display | 7 inch 800*480 dot-matrix TFT touchscreen |
Interface | USB2.0 × 2; MicroSD × 1, up to 64GB |
Storage | Internal 8GB Flash memory; External support U disk storage |
Battery | 7.4V 5300mAh Battery, 39.22Wh Maximum 4 hours operating time |
Battery Life | Over 3 hours |
Battery charge time | 5 hours to full charge |
Supported rates | 10-BaseT, 100-BaseTX, 1000Base-T, 1000Base-FX |
Supported standard | IEEE802.3, RFC 2544, Y.1564, IEEE1588v2 |
Support reference clock source | Internal high stability clock source, Ethernet line recovery clock, external clock (2.048Mbps, 1.544Mbps, 2.048MHz) |
Total power consumption | <12W |
Operating Temperature Range | -10~+50 |
Storage temperature range | -20~+70 |
Relative humidity | 0%-95% Non-condensing |
Dimensions (L*W*H) | 206mm*171 mm*75mm |
Weight | 1.5kg (3.3 lbs) |
