Specifications
RS232 GSM/GPRS modem with E-Device TCP/IP StackDriven through AT#
DNS, FTP, POP3, SMTP, TCP, UDP
STK,internet, SMS, data
Detailed Product Description
RS232 GSM/GPRS modem with E-Device TCP/IP Stack
Driven through AT#
DNS, FTP, POP3, SMTP, TCP, UDP
STK,internet, SMS, data
RS232 GSM/GPRS MODEM
Product description:
General Features
Industrial design
Aluminum casing
Wireless access to internet
Based on Simcom module SIM345
850/900/1800/1900MHZ
With E-Device TCP/IP Stack
Full TCP/IP stack driven through AT#
DNS, FTP, POP3, SMTP, TCP, UDP
3V SIM card slot
DB9 RS232 interface
SIM Application Toolkit
Double tone multi-frequency function (DTMF)
Support AT command to make remote control (GSM07.07 and 07.05)
GPRS Class 10
Antenna with high sensitivity
Always on-line
Conform with ETSI GSM Phase2+ standard
Output Power
Class 42W @850 900MHz
Class 11W @ 1800/1900MHz
Input voltage6V-36V DC
Input current1A-2A
Standby current: 56mA
Working current: 100-140mA
Working temperature -20 to +55 degrees
Storage temperature:-25 to -+70 degrees
Size76*54*25mm
Weight100g
Accessories: AC/DC adaptor, DB9 RS232 cable, antenna, 2 mounting plates, CD
Specifications for Data
GPRS class 10: max. 85.6 kbps (downlink)
· Full TCP/IP stack driven through AT#
· DNS, FTP, POP3, SMTP, TCP, UDP
· PBCCH support
· Coding schemes CS 1,2,3,4
· CSD up to 14.4 kbps
· USSD
· Non transparent mode
· PPP-stack
Specification for SMS
Point-to-point MO and MT
· SMS cell broadcast
· Text and PDU mode
