51mm 20KHz Ultrasonic Speaker (ROHS APPROVED)

51mm 20KHz Ultrasonic Speaker (ROHS APPROVED) thumbnail-1
51mm 20KHz Ultrasonic Speaker (ROHS APPROVED) photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
cosson
Model Number:
KS-5120
Contact Supplier Request Quote Chat Now
Dongguan Cosson Electronic Plastic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name cosson
Model Number KS-5120
Type Other, ultrasonic speaker, waterproof ultrasonic speaker

Specifications

51mm 20KHz ultrasonic speaker (ROHS APPROVED)
1.Frequency:20Khz;
2.Diameter:51mm;
3.other type of ultrasonic speaker: 40KHz.

PART_1:   More detail about ultrasonic speaker:

51mm 20KHz ultrasonic speaker
1.Frequency:20Khz
2.Diameter:20mm
3.Can be used for  pest repeller



Specification of the ultrasonic speaker

  1. Rated noise power:5.5Vp-p;
  2. Rated long Max. power:30Vp-p;
  3. Rated frequency range:2.5~60KHz;
  4. Operating frequency:20±5KHz;
  5. Rated Sensitivity:min.95dB;
  6. Operating Temperature:-10°c~+60°c;
  7. Storage Temperature:-10°c~+70°c;



External dimensions of the ultrasonic speaker:

51mm 20KHz ultrasonic speaker (ROHS APPROVED)



FREQUENCY characteristics:

51mm 20KHz ultrasonic speaker (ROHS APPROVED)

PART_2:   Other type of ultrasonic speaker:



No Model Frequency Name
1 KS-3840 40KHz±5KHz Ultrasonic speaker
2 KS-4140 40KHz±5KHz Ultrasonic speaker
3 KS-5120 20KHz±5KHz Ultrasonic speaker





Picture of 41mm ultrasonic speaker (KS-4140):

51mm 20KHz ultrasonic speaker (ROHS APPROVED)

Picture of 38mm ultrasonic sensor (KS-3840):

51mm 20KHz ultrasonic speaker (ROHS APPROVED)

Picture of 51mm ultrasonic speaker (KS-5120):

51mm 20KHz ultrasonic speaker (ROHS APPROVED)



Catalogue of ultrasonic speaker:



51mm 20KHz ultrasonic speaker (ROHS APPROVED)



PART_3:   About Us





We are specialize in producing electro-acoustic components such as BUZZER (piezoelectric buzzer/electromagnetic buzzer/mechanical buzzer/SMD buzzer), Piezoelectric ceramic element, Conderser microphone,ultrasonic sensor,Atomization piece,etc.



If interested in our prdoucts ,please contact us any time,Thank you



51mm 20KHz ultrasonic speaker (ROHS APPROVED)
