Place of Origin Guangdong, China
Brand Name COSSON
Model Number KS-5120(waterproof)
Type Other, Speaker, waterproof type

Specifications

1.waterproof ultrasonic speaker.
2.Sell fast for all over the world.
3.High quality and competitive price.
4.No MOQ.
5.ROHS.

KS-5120 waterproof  Ultrasonic Speaker

1.Specification:

No.

Item

Unit

Specification

Condition

1

Rated Noise Power

Vp-p

5.5Vp-p



2

Rated Long Max.Power

Vp-p

30Vp-p



3

Rated Frequency Range

KHZ

2.5-60KHz



4

Operating Frequency

KHZ

20±5KHz



5

Rated Sensitivity

DB

≥100dB

Square Wave

6

Operating Temp

°C

-10~60



7

Storage Temp

°C

-10~70



8

Dimension

mm

Φ51*H18

See appearance drawing

9

Environmental

Protection Regulation



 RoHS



2.External dimensions:

Unit:mm    TOL:±0.5

 waterproof Ultrasonic Speaker

3.FREQUENCY characteristics:

 waterproof Ultrasonic Speaker

4.TESTING METHOD

Standard Measurement conditions

Temperature:25±2°C  Humidity:45-65%



Acoustic Characteristics:

The oscillation frequency, current consumption and sound pressure are measured by the

measuring instruments shown below

waterproof Ultrasonic Speaker

5.ENVIRONMENT TEST

NO.

ITEM

TEST CONDITION AND REQUIREMENT

1

High Temperature

Test (Storage)

After being placed in a chamber with 70ï2ºC for 96 hours and then

being placed in normal condition for 2 hours.

Allowable variation of SPL after test: ï10dB.

2

Low Temperature

Test (Storage)

After being Placed in a chamber with -20ï2ºC for 96 hours and then

being placed in normal condition for 2 hours.

Allowable variation of SPL after test: ï10dB.

3

Humidity Test

After being Placed in a chamber with 90-95% R.H. at 40ï2ºC for 96

hours and then being placed in normal condition for 2 hours.

Allowable variation of SPL after test: ï10dB.

4

Temperature Cycle

Test

The part shall be subjected to 5 cycles. One cycle shall be consist of:

 waterproof Ultrasonic Speaker



Allowable variation of SPL after test: ï10dB.

TEST CONDITION.

Standard Test Condition :

a) Temperature : +5 ~ +35°C

b) Humidity : 45-85%

c) Pressure : 860-1060mbar



Judgment Test Condition :

a) Temperature : +25 ± 2°C

b) Humidity : 60-70%

c) Pressure : 860-1060mbar
