1.Product description
Stable performance, sock toes are straight, tidy and even, quick and efficient, automatic work under computer control, easy to operate, low requirements for operators,the head of the sewing machine can lift automatically, the motor can return in any point when started, convenient maintenance, it is the ideal product in the field of sock sewing machines.
2.Functions and characteristics
can send socks, focus ,parallel toe,cut the line reverse socks automatically
can regulate the speed arbitrarily, suck yarn automatically,low noise, safe and environmental
the head of the sewing machine can lift automatically, the motor can return in any point when started
flexible control, easy to operate,efficient and durable
change frequency by computer,stop automatically when yarns are breaking
change coil density by changing gear
turbo box is sealing lubricate automatically
equipped with equipments at random
3. main specifications
efficiency4 00—700P/H
NEEDLE RANGE 80—240N
power 180W/48V Appropriate current200V/50HZ,110V/60HZ
packing size 1060×560×1300
4. installation
open the packing box,read the instructions carefully
put the machine on the ground stably, adjust the foot screw of the machine (see chart 1), make the machine level
remove the plastic cover, clean the machine body and oil with brush or cloth
Check the power supply voltage and motor voltage are matching or not, make sure the power line is connected
use the manual wheel after the motor functioned(see chart 1), check whether every part is normal and has no noise(screw thread loose in transition).
plug the power cord, start the "play, operate hand pressure feeding switch " buttons, and check the rotation direction
threading and try sewing socks
5. sock sewing and use suggestions
for achieve the best effect of the product, when sock knitting finished, we suggest:
weave four items with fine woven nylon yarn(about 7-8), to be thinner nylon yarn parts
then wove12-16 items with roving woven yarns, constitute the thicker edge
if the sock body is rib organization, you can weave flat in front of sock toe about1cm
dry and superior quality 35D nylon is good for seaming head
