B HD-CCTV-PVC/C single phase surge protective device
- 10000 Set / Sets per Month
- Guangzhou
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Haide | Model Number: | HD-CCTV-PVC/C |
Product Description
Specifications
single phase surge protective device1.GB 18802.21-04 & IEC 61643-1-05
2.CE & ISO9001
3.Video lightning arrester
B HD-CCTV-PVC/C single phase surge protective device
single phase surge protective device
This product is applicable to the lightning and electric surge protection of the video signal circuit, control wiring and power circuit of monitor camera. It can combine the above mentioned lightning protection function into one. Its housing adopts integrated aluminum-alloy structure with small volume and ultra low residual pressure output. Design of this product considers fully that the electrode capacitance and distributed capacitance would lessen data signaling with small insertion loss, which can satisfy the requirement of video signal transmission, and can response to the transient overvoltage quickly.
Model | HD-CCTV-PVC/C | ||
Video line | Power ciruit | Control wiring | |
Nominal working voltage Un | ±5V | 12/24/220V | 6.8/12/24V |
Maximum continuous working voltage Uc | ±6.8V | 16/32/275V | 7.5/15/32V |
Nominal discharge current In(8/20us) | 1.5KA | 5KA | 1.5KA |
Maximum discharging current Imax(8/20us) | 3KA | 10KA | 3KA |
1KV/us Voltage protection level Up | 15V | 16/25/42V | |
Limiting voltage Up | 150/200/600V | ||
Insertion loss | ≤0.2dB | ≤0.2dB | |
Insertion resistance | ≤4Ω | ≤4Ω | |
Band width | 40MHz | ||
Message transmission rate Vs | 2MHz | ||
Protection grade | IP30 | ||
External dimension | 108*63.5*28mm | ||
Sheathing material | Shielding metallic aluminium | ||
Interface mode | BNC | Connecting terminla | Connecting terminla |
1.ISO9001&CE certificate;
2.Any inquiries will be replied within 24 hours;
3.Professional manufacture:
Welcome to our website:http://gzhaidefanglei.cn.china.cn/
4.High quality, fashion designs, reasonable &competitive price, fast lead time;
5.OEM available;
6.After-Sale Service:
·Provide technical advice and maintenance knowledge and installation guide;
·Customers response time for one working time;
·All the products provide five year commitment to service;
·All the products are accompanied by China Pacific property insurance co;ltd.
7.Fast delivery:
Sample order in stock, and 7-15 working days for full production;
8.Terms of payment:
You can pay for the order via: T/T, Western Union, PayPal &Money Gram;
9.Shipping:
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Port. You also can choose your own shipping forwarder;
10.Quality warranty:
5 years warranty
single phase surge protective device
