Specifications
lightning arrestor surge protector1.GB 18802.21-04 & IEC 61643-1-05
2.CE & ISO9001
3.Video lightning arrester
B HD-CCTV-PV/B lightning arrestor surge protector
lightning arrestor surge protector
The product can carry out surge protection respectively of the power supply and video lines of a camera, the enclosure adopts an integral aluminum alloy structure, the product has a small volume and very low output residual voltage, has little insertion loss because the interelectrode capacitance of devices and the attenuation of advantage of rapid response to transient over-voltage.
| Model | HD-CCTV-PV/B | |
| Video line | Power ciruit | |
| Nominal working voltage Un | ±5V | 12/24/220V |
| Maximum continuous working voltage Uc | ±6.8V | 16/32/275V |
| Nominal discharge current In(8/20us) | 5KA | 5KA |
| Maximum discharging current Imax(8/20us) | 10KA | 10KA |
| 1KV/us Voltage protection level Up | 15V | |
| Limiting voltage Up | 150/200/600V | |
| Insertion loss | ≤0.2dB | |
| Insertion resistance | ≤1Ω | |
| Band width | 40MHz | |
| Protection grade | IP30 | |
| External dimension | 108*63.5*28mm | |
| Sheathing material | Shielding metallic aluminium | |
| Interface mode | BNC | Connecting terminla |
1.ISO9001&CE certificate;
2.Any inquiries will be replied within 24 hours;
3.Professional manufacture:
Welcome to our website:https://img13.fr-trading.com/
4.High quality, fashion designs, reasonable &competitive price, fast lead time;
5.OEM available;
6.After-Sale Service:
·Provide technical advice and maintenance knowledge and installation guide;
·Customers response time for one working time;
·All the products provide five year commitment to service;
·All the products are accompanied by China Pacific property insurance co;ltd.
7.Fast delivery:
Sample order in stock, and 7-15 working days for full production;
8.Terms of payment:
You can pay for the order via: T/T, Western Union, PayPal &Money Gram;
9.Shipping:
We have strong cooperation with DHL, TNT, UPS, FEDEX, EMS, China Air Port. You also can choose your own shipping forwarder;
10.Quality warranty:
5 years warranty
lightning arrestor surge protector
