Main Feature:
1. First Patent of Out Cool Air Circulation to Sink the Heat Technology(Patent No.ZL201220269676.7)
2. First Patent of Video Analysis Light-adjustment Technology .(Patent No.201110089768.7)
3. The Highly power array LEDs with IR range up to 100 meters
4. Unique composite lens design, to enhance the effect of night vision.
5. Patent external wiper design, to make sure the HD image is clearer all day.(Optional configuration).
6. Built in power with wall mounted bracket design, making it more convenient for maintenance on site.
7. Auto tracking function for unman surveillance
Technical parameters |
| |
Model | RDC205FHPT-K20HA-W1 | |
Image Sensor | 1/3 CCD hikvision Sensor | |
Definition | 720P | |
Focus length | 20X Optical Zoom | |
communication protocol | PAL/NTSC | |
Day/night mode | Automatic/multicolour/monochroma (ICR) | |
Focus mode | Automatic/manual | |
S/N | > 50dB | |
BLC | 0 ~ 20 | |
White banlance | Automatic/manual | |
Electronic shutter | Off / On (Max 42dB) | |
AGC | Auto / Shutter PRI / Iris PRI / Manual | |
Min illumination | Color: 0.08Lux(F1.6.30IRE) Black/White: 0.02Lux (F1.6.30IRE) | |
OSD Manu | English/ Chinese | |
Infrared lamp | ||
IR distance | 100 meters | |
IR lamp | The OSRAM/High power Arrany LEDs with IR | |
IR power | 16w | |
IR Lens | Combination lens | |
Speed dome camera | ||
Pan speed | Pan speed 0.01°/s~360°/s | |
Tilt speed | Tilt speed 0.01°/s~120°/s | |
Rotation | Pan :0~90° continuous rotation tilt:-10~90° auto flip | |
Preset | 256 preset (chinese tilt) | |
Auto scan | 8 groups, settable boundaries and scan speed | |
Auto cruise | 8 groups each with 32 presets with settable time interval | |
Pattern tour | 4 groups each with 500 instructions | |
Video analysis | support | |
Auto track | yes | |
OSD Manu | English/ Chinese | |
Timing Action | RTC clock design for timing events during the whole week | |
Wiper | yes | |
Power box | optional | |
Heat dispersion | Out Cool Air Circulation to Sink the Heat Technology | |
Supply voltage | DC12V+10% | |
Levels of protection | IP66/Level2 lightness protection,4000w prvent thunderbolt surges design | |
Working temperature | -35℃-+55℃ | |
Working humidity | <90% No condensation | |
Consumption | Max 38W | |
Weight | 4.8kg | |
Accessory | Wall -mount bracket DC 12 Power | |
