Welding Fin Cooling Pipe Coils with Extruded Aluminium Louver for Gas Furnace Tubing

Name: Welding Fin Cooling Pipe Coils with Extruded Aluminium Louver for Gas Furnace Tubing
Brand: GZGELE
Availability: InStock

FOB Price

USD $10 - $250 / Unit

1 Unit(Min.Order)

Supply Ability 200 Unit / Units per Month
Port Guangzhou China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Guangdong, China
Brand Name	GZGELE	Model Number	fin tubes
Structure	Tube Heat Exchanger	Liquid Flow Rate	adjustable
Maximum Working Pressure	3.0MPa	Voltage	Variable
Weight	customized	Dimension(LWH)	customized
Power(W)	N/A	Certification	CE, Other, CE, ISO9001:2008
Warranty	1 year	After-sales Service Provided	No overseas service provided

Product Description

Finned tubes / Spiral Pipes for Heat Exchanger& radiator

Product Description

Tube material: GB8163 grade carbon steel, A179 Grade/ S/S304 or S/S316 Grade stainless steel, Coppe

Fin material: GB8163 grade carbon steel, A179 Grade/ S/S304 or S/S316 Grade stainless steel, Copper, Aluminium

Processing/ Structure: spiral finned tube, extruded finned tube, strainght finned tube

Making Standard: GB/T14296-93

Fin tube detailed specification
Material	Specification	Fin OD	Heat exchanging area(M2)	Fin height	Fin thickness	Fin distance
Carbon steel tube with extruded aluminium fin	ODΦ18 X 2.0	Φ38	0.72	10	0.3	3
	ODΦ21 X 2.0	Φ45	0.96	12	0.3	3
	ODΦ21 X 2.0	Φ51	1.15	15	0.3	3
	ODΦ25 X 2.5	Φ50	1.2	12.5	0.3	3
	ODΦ25 X 2.5	Φ55	1.37	15	0.3	3
	ODΦ32 X 2.5	Φ62	1.56	15	0.3	3

Carbon steel tube with crimped carbon steel fin	ODΦ18 X 2.0	Φ38	0.57	10	0.3	4 to 5
	ODΦ21 X 2.0	Φ51	0.68	15	0.3	5 to 8
	ODΦ21 X 2.0	Φ45	0.76	12	0.3	5 to 8
	ODΦ25 X 2.5	Φ50	0.96	15	0.3	5 to 8
	ODΦ25 X 2.5	Φ55	1	15	0.3	5 to 8
	ODΦ32 X 2.5	Φ62	1.1	15	0.3	8 to 10
	ODΦ32 X 2.5	Φ72	1.21	20	0.3	8 to 10

Stainless steel tube with crimped stainless steel fin	ODΦ18 X 2.0	Φ38	0.62	10	0.3	4
	ODΦ21 X 2.0	Φ51	0.75	15	0.3	5
	ODΦ21 X 2.0	Φ45	0.87	12	0.3	5
	ODΦ25 X 2.5	Φ50	1	12.5	0.3	5
	ODΦ25 X 2.5	Φ55	1.25	15	0.3	5

Stainless steel tube with extruded aluminium fin	ODΦ18 X 2.0	Φ38	0.72	10	0.3	3
	ODΦ21 X 2.0	Φ51	0.96	12	0.3	3
	ODΦ21 X 2.0	Φ45	1.15	15	0.3	3
	ODΦ25 X 2.5	Φ50	1.2	12.5	0.3	3
	ODΦ25 X 2.5	Φ55	1.37	15	0.3	3
	ODΦ32 X 2.5	Φ62	1.56	15	0.3	3
All the unite is in mm

The specification can be designed as per customer's requirement.

Product Applications

End Application of Gele Heat Exchanger/ Radiator included GREENHOUSE, timber dryer, dry kiln, gravure printing M/C,printing and dyeing M/Dyeing and

finishing M/C, hot air stenter M/C,heat framing M/C, drying M/C, textile printing M/C,flat bed printing M/C, roto screen

printing M/C, ,rotogravure printing machine M/C;drying foodstuff, tea leaf, airconditioner; airflow drying starch

(starch dryer) and feedstuff, paper M/C,vegetable dehydration tunnel, oven drying , drying machine for plastic & leather

grunting , CAC heating and refrigeration, workshop constant temperature warming, drying and cooling brewer's malt,

tobacco splitting, swelling & drying ,drying dyestuff, chemical fiber, soda, latex, PVC, glutin , leather finishing M/C,

blanket setting machine, Laminating M/C, Oven

Production Flow

Heat exchanger manufacturing process in our factory
